DEATTI Q30S PTZ Outdoor Surveillance Camera User Manual

1. Introducere

This manual provides detailed instructions for the installation, operation, and maintenance of your DEATTI Q30S PTZ Outdoor Surveillance Camera. Designed for robust outdoor use, this camera offers 1080P resolution, Wi-Fi connectivity, two-way audio, and advanced motion detection features to enhance your security.

Please read this manual thoroughly before using the product to ensure proper setup and to maximize its functionality and lifespan.

Figure 1.1: DEATTI Q30S PTZ Outdoor Surveillance Camera and App Interface

The DEATTI Q30S camera is shown alongside a smartphone displaying its live 2K video feed, demonstrating its remote viewcapacitatea de ing.

2. Configurare

2.1 Ce se află în cutie

Verificați dacă toate componentele sunt prezente în pachet:

• DEATTI Q30S PTZ Outdoor Surveillance Camera
• Adaptor de alimentare
• Șuruburi de montare și dibluri de perete
• Manual de instructiuni

Figura 2.1: Conținutul pachetului

This image displays all items included in the DEATTI Q30S camera package: the camera unit, power adapter, mounting hardware, and the user manual.

2.2 Instalare fizică

The DEATTI Q30S camera is designed for wall mount installation. Choose a location that provides optimal viewing coverage and is within range of your Wi-Fi network and a power outlet.

1. Mark the drilling points on the wall using the camera's mounting bracket as a template.
2. Dați găuri și introduceți diblurile de perete.
3. Fixați suportul de montare pe perete folosind șuruburile furnizate.
4. Attach the camera to the mounted bracket, ensuring it is firmly in place.

Figure 2.2: Camera Mounted Outdoors

The camera is shown securely mounted on an exterior wall, illustrating a typical installation scenario for outdoor surveillance.

2.3 Conexiune la alimentare

Connect the power adapter to the camera's power input port and then plug it into a standard electrical outlet. Ensure the connection is secure to prevent power interruptions.

2.4 Instalarea aplicației și configurarea inițială

The DEATTI Q30S camera is controlled via a dedicated mobile application. Download the app from your device's app store (iOS or Android).

1. Deschide aplicația și creează un cont sau autentifică-te.
2. Follow the in-app instructions to add your new camera. This typically involves scanning a QR code on the camera or connecting to its temporary Wi-Fi hotspot.
3. Connect the camera to your home 2.4GHz Wi-Fi network. (Note: 5GHz Wi-Fi is not supported).
4. Complete the setup process, including setting a secure password for your camera.

3. Operarea camerei

3.1 Funcționalitate Pan și Tilt

The camera features Pan-Tilt-Zoom (PTZ) capabilities, allowing for a 360-degree field of view. You can remotely control the camera's horizontal (pan) and vertical (tilt) movement through the mobile app.

• Tigaie: 355 degrees horizontal rotation.
• Înclinare: 90 degrees vertical rotation.

Figure 3.1: Pan and Tilt Capabilities

This image illustrates the camera's ability to pan 355 degrees horizontally and tilt 90 degrees vertically, providing comprehensive area coverage.

3.2 PIR Motion Detection and Auto Tracking

The camera is equipped with a Passive Infrared (PIR) human motion sensor. When motion is detected, the camera can automatically track the moving object and send real-time alerts to your smartphone.

• Senzor PIR: Detects heat signatures from humans, reducing false alarms.
• Urmărire automată: The camera automatically follows detected motion within its field of view.
• Mesaj Push: Primește notificări instantanee pe telefon atunci când detectează mișcare.

Figure 3.2: PIR Motion Detection and Auto Tracking

This image demonstrates the camera's PIR motion detection and auto-tracking feature, showing how it follows a person's movement.

3.3 Sunet bidirecțional

The built-in microphone and speaker allow for two-way communication. You can listen to what's happening around the camera and speak through the camera using your smartphone app.

• Communicate with visitors or delivery personnel.
• Deter intruders with a verbal warning.

Figura 3.3: Funcționalitate audio bidirecțională

This image illustrates the two-way audio feature, showing a user communicating with a delivery person through the camera.

3.4 Vedere nocturnă

The DEATTI Q30S provides clear night vision up to 20 meters, ensuring surveillance even in low-light or complete darkness. It features both infrared (IR) and spotlight-enhanced night vision modes.

• Viziune de noapte în infraroșu: Oferă filmare alb-negru în întuneric complet.
• Color Night Vision (Spotlight On): Activates built-in spotlights to provide full-color video at night.

Figure 3.4: 2K Clear Night Vision

This image compares the camera's night vision capabilities, showing clear black-and-white infrared vision and enhanced color vision with spotlights activated.

3.5 Înregistrare și stocare 24/7

Camera acceptă înregistrare continuă 24/7. Înregistrare videotage poate fi stocat în două moduri:

• Stocare în cloud: Subscribe to cloud storage services through the app for secure, remote access to your recordings.
• Stocare locală: Insert a Micro SD card (up to 128GB, not included) into the camera's designated slot for local recording. The slot is typically located under a protective cover or near the reset button.

Figure 3.5: 24/7 Recording Options

This image highlights the camera's 24/7 recording capability, offering both cloud storage and local storage via a 128GB TF card (not included).

3.6 Alarmă de detectare a mișcării

Beyond simple notifications, the camera can trigger an alarm response upon detecting motion, enhancing security measures.

• Sirenă încorporată: An audible alarm can be activated to deter intruders.
• În centrul atenției: The camera's spotlights can illuminate the area, making intruders visible and potentially scaring them away.

Figura 3.6: Alarmă de detectare a mișcării

This image depicts the camera's motion detection alarm system, showing a spotlight illuminating an intruder and a notification on a smartphone.

4. Întreținere

4.1 Curățarea camerei

To ensure optimal performance and clear image quality, periodically clean the camera lens and housing. Use a soft, dry cloth to wipe away dust and dirt. For stubborn marks, a slightly damp cloth can be used, followed by a dry wipe. Avoid abrasive cleaners or solvents.

4.2 Environmental Considerations (IP66 Weatherproof)

The DEATTI Q30S camera is rated IP66 weatherproof, meaning it is protected against dust ingress and powerful water jets. This makes it suitable for outdoor use in various weather conditions, including rain and snow. However, extreme temperatures outside its operating range should be avoided.

Figura 4.1: Design rezistent la intemperii IP66

This image emphasizes the camera's IP66 weatherproof rating, showing its resilience against sun, rain, and snow, making it ideal for outdoor environments.

5. Depanare

5.1 Probleme comune și soluții

• Aparat foto offline:
  • Verificați conexiunea de alimentare.
  • Ensure Wi-Fi signal strength is adequate at the camera's location.
  • Reporniți camera deconectând și reconectând alimentarea.
  • Verify your router is functioning correctly.
• Fără alerte de detectare a mișcării:
  • Check app settings to ensure motion detection and notification alerts are enabled.
  • Ajustați setările de sensibilitate la mișcare în aplicație.
  • Asigurați-vă că nu există obstacole care blochează camera view.
• Calitate slabă a imaginii:
  • Curățați obiectivul camerei.
  • Ensure adequate lighting, especially at night (check night vision settings).
  • Verify your internet connection speed is stable.
• Cardul SD nu înregistrează:
  • Ensure the SD card is inserted correctly.
  • Format the SD card through the app.
  • Check if the SD card is faulty or has reached its capacity.

If issues persist, refer to the in-app help section or contact DEATTI customer support.

6. Specificații

Detailed technical specifications for the DEATTI Q30S PTZ Outdoor Surveillance Camera:

7. Garanție și asistență

For information regarding product warranty, please refer to the warranty card included with your purchase or visit the official DEATTI webTermenii și condițiile de garanție pot varia în funcție de regiune.

For technical support, troubleshooting assistance beyond this manual, or general inquiries, please contact DEATTI customer service through the contact information provided on the official website sau în cadrul aplicației mobile.

Resurse online:

• Official DEATTI Website: www.deatti.com (Vă rugăm să rețineți: Acesta este un substituent) URL. Refer to your product packaging for the correct website.)
• In-App Help Section
