Manual de utilizare pentru scanerul OBD2 FOXWELL NT716 și testerul de baterii BT60

1. Introducere

This manual provides detailed instructions for the operation and maintenance of your FOXWELL NT716 OBD2 Bidirectional Scan Tool and FOXWELL BT60 6V/12V Wireless Car Battery Tester. Please read this manual thoroughly before using the devices to ensure proper function and to prevent damage. Keep this manual for future reference.

2. Produs terminatview

2.1 FOXWELL NT716 OBD2 Bidirectional Scan Tool

The FOXWELL NT716 is a professional diagnostic scan tool designed for comprehensive vehicle system analysis. It offers advanced features including bidirectional control, 9 reset functions, and diagnostics for 4 main systems (Engine, Transmission, ABS, SRS).

Image 2.1: The FOXWELL NT716 OBD2 Scanner (left) and BT60 Battery Tester (right). The NT716 features a large display and robust casing, while the BT60 is a compact, handheld device with battery clamps.

• Control bidirecțional: Perform active tests to control various vehicle components.
• 9 Reset Functions: Includes Oil Light Reset, ABS Bleeding, BMS Reset, SAS Reset, DPF Reset, Injector Coding, TPMS Reset, EPB Reset, and Throttle Reset.
• 4 System Diagnostics: Comprehensive scanning for Engine, Transmission, Anti-lock Braking System (ABS), and Supplemental Restraint System (SRS).
• Funcții OBDII complete: Read/Erase Codes, Live Data, Freeze Frame Data, I/M Readiness, O2 Sensor Test, On-Board Monitor Test, Component Test, Vehicle Information.
• Actualizări gratuite: Ensures access to the latest vehicle data and software enhancements.

2.2 FOXWELL BT60 6V/12V Wireless Car Battery Tester

The FOXWELL BT60 is an innovative, app-supported battery tester designed for 6V and 12V automotive batteries. It connects wirelessly via Bluetooth to your smartphone, providing detailed battery health analysis and report sharing capabilities.

Image 2.2: The FOXWELL BT60 Wireless Battery Tester highlighting its versatile features including State of Health (SOH), State of Charge (SOC), Load Test, Battery Voltage, Resistance Test, Cranking Test, Ripple Test, Data Storage, and Data Share.

• Conectivitate wireless: Bluetooth 5.3 for seamless connection to the BT60 App on your smartphone.
• Analiză completă a bateriei: Measures State of Health (SOH), State of Charge (SOC), Battery Voltage, Internal Resistance, Cranking Test, and Charging System Ripple Test.
• App-Supported: Manage multiple battery records, share diagnostic reports, and access quick start guides directly from the app.
• Compatibilitate largă: Supports 6V and 12V batteries.

3. Configurare

3.1 FOXWELL NT716 Setup

1. Pornire: Connect the NT716 to the vehicle's OBD-II port. The device will power on automatically.
2. Configurație inițială: Follow the on-screen prompts to select language, time zone, and other initial settings.
3. Actualizare software: Connect the NT716 to a computer with internet access and use the FOXWELL update tool to ensure the latest software is installed. This provides access to the most current vehicle data and functions.

3.2 FOXWELL BT60 Setup

1. Descărcați aplicația: Download and install the "FOXWELL BT60" application from your smartphone's app store (iOS or Android).
2. Charge BT60: Ensure the BT60 device is adequately charged before first use.
3. Conectați la baterie: Atașați cl roșuamp la terminalul pozitiv (+) și cl negruamp la borna negativă (-) a bateriei vehiculului.
4. Asociere Bluetooth:
   • Open the BT60 App on your smartphone.
   • Asigurați-vă că Bluetooth este activat pe telefon.
   • The app will automatically search for and connect to the BT60 device. Confirm the pairing if prompted.

Image 3.2: The FOXWELL BT60 connected to a car battery, demonstrating its wireless Bluetooth 5.3 connection to a smartphone app for remote testing and monitoring.

4. Instrucțiuni de utilizare

4.1 Using the FOXWELL NT716 OBD2 Scanner

1. Conectați-vă la vehicul: Plug the NT716 into the vehicle's OBD-II port (usually located under the dashboard).
2. Selectați vehiculul: From the main menu, select the vehicle manufacturer and model.
3. Alegeți funcția: Navigate through the menu to select the desired diagnostic function.

4.1.1 4 System Diagnostic

This function allows you to read and clear diagnostic trouble codes (DTCs), view live data, and retrieve freeze frame data for the Engine, Transmission, ABS, and SRS systems.

Image 4.1.1: The FOXWELL NT716 displaying its 4-system diagnostic capabilities, including Engine, Transmission, ABS, and SRS, along with full OBDII functions, live data, and code reading/erasing.

• Citiți codurile: Displays current, pending, and permanent DTCs.
• Ștergeți codurile: Clears DTCs from the vehicle's computer. Ensure the underlying issue is resolved before clearing codes.
• Date live: Shows real-time data streams from various sensors and components.

4.1.2 Control bidirecțional (test activ)

Bidirectional control allows the scan tool to send commands to the vehicle's ECUs to perform specific tests and functions, such as activating components to verify their operation.

Image 4.1.2: The FOXWELL NT716 demonstrating bidirectional control, allowing the user to send commands to vehicle components like injectors, fuel pump, cooling fan, and A/C relay for active testing.

• Injector Test: Activates individual injectors to check their functionality.
• Fuel Pump Test: Commands the fuel pump to turn on/off.
• Cooling Fan Test: Activates the engine cooling fan.
• A/C Relay Test: Tests the air conditioning compressor relay.

4.1.3 Special Functions (Resets)

The NT716 supports 9 commonly used special reset functions for various vehicle systems.

Image 4.1.3: The FOXWELL NT716 displaying its 9 special functions, including Oil Light Reset, ABS Bleeding, BMS Reset, SAS Reset, DPF Reset, Injector Coding, TPMS Reset, EPB Reset, and Throttle Reset.

• Resetare martor ulei: Resetează martorul luminos de service al uleiului după un schimb de ulei.
• Sângerare ABS: Efectuează proceduri de aerisire pentru sistemul de frânare antiblocare.
• Resetare BMS: Resetează sistemul de gestionare a bateriei după înlocuirea bateriei.
• Resetare SAS: Calibrează senzorul de unghi de direcție.
• Resetare DPF: Resets the Diesel Particulate Filter system.
• Codarea injectoarelor: Codifică noile valori ale injectoarelor în ECU.
• Resetare TPMS: Resetează sistemul de monitorizare a presiunii în anvelope.
• Resetare EPB: Resetează frâna electronică de parcare după înlocuirea plăcuțelor de frână.
• Resetare accelerație: Relearns throttle body position.

4.2 Using the FOXWELL BT60 Battery Tester

Once the BT60 is connected to the battery and paired with the app, you can perform various tests.

Image 4.2: The FOXWELL BT60 app interface showing battery status at a glance, including tested capacitance, voltage, battery health, state of charge, and resistance. It also displays results for cranking and charging tests.

4.2.1 Testul bateriei

1. Open the BT60 App and select "Battery Test".
2. Input battery information (type, standard, CCA) if prompted, or select from saved profiles.
3. The app will display the battery's State of Health (SOH), State of Charge (SOC), Voltage, and Internal Resistance.

4.2.2 Test de pornire

This test measures the battery's ability to provide current during engine cranking.

1. Selectați „Test de pornire” în aplicație.
2. Follow the on-screen instructions to start the engine.
3. The app will display the cranking voltage and time, indicating the battery's performance during startup.

4.2.3 Test de încărcare

Evaluates the vehicle's charging system (alternator, regulator) performance.

1. Selectați „Test de încărcare” în aplicație.
2. Follow the on-screen instructions to rev the engine to specified RPMs.
3. The app will display charging voltage and ripple, indicating the health of the charging system.

4.2.4 Data Management and Sharing

Image 4.2.4a: The FOXWELL BT60 app interface showing options for managing multiple batteries, accessing data records, and utilizing online quick guides and diagnosis result definitions.

Image 4.2.4b: The FOXWELL BT60 app demonstrating the ability to share diagnostic reports via images or text, allowing for easy communication of battery health information.

• Manage Multiple Batteries: The app allows you to save and manage test records for various batteries.
• Data Records: Access historical test data for comparison and trend analysis.
• Partajați rapoarte: Generate and share diagnostic reports via email, messaging apps, or other platforms directly from the app.

5. Întreținere

• curatenie: Folosiți un moale, damp lavetă pentru curățarea dispozitivului casings. Do not use abrasive cleaners or solvents.
• Depozitare: Store the devices in a dry, cool environment away from direct sunlight and extreme temperatures.
• Îngrijirea cablului: Inspect cables and connectors regularly for damage. Replace if necessary.
• Actualizări de software: Regularly update the NT716 software via the FOXWELL update tool and ensure the BT60 app is updated to the latest version for optimal performance and compatibility.

6. Depanare

• Device Not Powering On (NT716):
  • Ensure the OBD-II cable is securely connected to both the vehicle and the scanner.
  • Verificați dacă aprinderea vehiculului este în poziția ON.
  • Verificați siguranța vehiculului pentru portul OBD-II.
• BT60 Not Connecting to App:
  • Asigurați-vă că Bluetooth este activat pe smartphone-ul dvs.
  • Verify the BT60 device is powered on and connected to the battery.
  • Restart the BT60 app and try pairing again.
  • Check if the BT60 device has sufficient charge.
• Citiri inexacte:
  • Asigurați-vă că bateria clamps are clean and securely attached to the battery terminals.
  • Verify the battery type and CCA values entered in the BT60 app are correct.
  • For NT716, ensure the correct vehicle information is selected.
• Probleme legate de actualizarea software-ului:
  • Ensure a stable internet connection during updates.
  • Temporarily disable antivirus software if it interferes with the update process.

7. Specificații

7.1 FOXWELL NT716 OBD2 Scanner

7.2 FOXWELL BT60 Battery Tester

8. Garanție și asistență

FOXWELL products typically come with a limited warranty. Please refer to the warranty card included with your product or visit the official FOXWELL website-ul pentru termenii și condițiile detaliate ale garanției.

For technical support, product inquiries, or service, please contact FOXWELL customer support through their official website or the contact information provided in your product packaging. Regular software updates are available to enhance functionality and compatibility.

• Oficial Website: www.foxwelltech.com (Examplinkul, vă rugăm să verificați realitatea URL)
• Serviciu clienți: Consultați ambalajul produsului sau website pentru detalii de contact.
