Introducere
Welcome to the user manual for your Cinnado Indoor 2K 3600 WiFi Security Camera. This guide provides comprehensive instructions to help you set up, operate, and troubleshoot your camera, ensuring optimal performance for your home security needs.
Image: The Cinnado Indoor 2K 3600 WiFi Security Camera, a compact white device with a dark lens, designed for indoor surveillance.
Înființat
Follow these steps for effortless setup and to get your camera online and monitoring in minutes.
- Despachetați camera: Carefully remove the camera and all accessories from the packaging.
- Pornire: Connect the power adapter to the camera and plug it into a power outlet. The camera will initiate its startup sequence.
- Descărcați aplicația: Caută the "Cinnado Smart" app (or similar) on your smartphone's app store (iOS or Android) and install it.
- Creați un cont: Deschide aplicația și creează un cont nou sau conectează-te dacă ai deja unul.
- Adăugați dispozitiv: In the app, tap the "+" icon to add a new device. Select "Security Camera" or "Smart Camera" from the list.
- Conectați-vă la Wi-Fi: Follow the on-screen prompts to connect your camera to your 2.4GHz Wi-Fi network. You may need to scan a QR code displayed on your phone with the camera's lens.
- Plasare: Poziționați camera în locația dorită, asigurându-vă că are o vizibilitate clară. view și se află în raza de acțiune Wi-Fi.
Operarea camerei
Master the features of your Cinnado camera to maximize its potential for comprehensive surveillance.
3600 Vision (Pan, Tilt, Zoom)
The camera offers a full 3600 panoramic view. Use the controls within the mobile app to remotely pan (rotate horizontally), tilt (rotate vertically), and digitally zoom to capture every angle, leaving no blind spot.
- Pan/Tilt: Drag your finger across the live view screen in the app to move the camera's lens.
- Zoom: Pinch in or out on the live view screen to digitally zoom.
- Poziții prestabilite: Set up specific viewing angles as presets for quick navigation.
Crystal-Clear 2K Resolution
Your camera records in stunning 2K resolution, providing sharp and detailed images. To optimize image quality:
- Asigurați o iluminare adecvată în zona monitorizată.
- Clean the camera lens regularly with a soft, dry cloth.
- Check your Wi-Fi signal strength; a strong signal ensures smooth 2K streaming.
Caracteristici avansate
- Detectarea mișcării: Configure motion detection zones and sensitivity levels in the app. You will receive instant alerts on your smartphone when motion is detected.
- Audio bidirecțional: Use the built-in microphone and speaker to communicate with people near the camera. Tap the microphone icon in the app's live view a vorbi.
- Stocare în cloud și stocare locală: Your camera supports both cloud storage (subscription may be required) and local storage via a microSD card (not included). Insert a microSD card into the designated slot for continuous recording or event-triggered recording.
- Vedere de noapte: Camera comută automat la vedere nocturnă în infraroșu în condiții de lumină slabă, oferind imagini clare alb-negru.tage.
Întreţinere
Proper maintenance ensures the longevity and optimal performance of your Cinnado security camera.
- curatenie: Gently wipe the camera lens and body with a soft, dry, lint-free cloth. Do not use harsh chemicals or abrasive cleaners.
- Actualizări firmware: Regularly check the app for available firmware updates. Keeping your camera's firmware up-to-date ensures you have the latest features and security enhancements.
- Ciclu de alimentare: If the camera becomes unresponsive, unplug it from the power source for 10 seconds, then plug it back in to perform a power cycle.
Depanare
This section addresses common issues you might encounter and provides solutions to ensure your camera is always protecting what matters most.
| Problemă | Cauza posibila | Soluţie |
|---|---|---|
| Camera este offline/Nu se poate conecta la Wi-Fi | Weak Wi-Fi signal, incorrect Wi-Fi password, camera too far from router, 5GHz Wi-Fi network. |
|
| Calitate a imaginii neclară sau slabă | Lentilă murdară, iluminare insuficientă, probleme cu lățimea de bandă a rețelei. |
|
| Detectarea mișcării nu funcționează | Incorrect sensitivity settings, detection zone not configured, app notifications disabled. |
|
| Audio bidirecțional nu funcționează | Microphone/speaker muted in app, low volume, network delay. |
|
Specificații
Key technical specifications for the Cinnado Indoor 2K 3600 WiFi Security Camera.
- Rezoluţie: 2K (2304 x 1296 pixeli)
- Câmpul de View: 3600 Horizontal Pan, Vertical Tilt
- Conectivitate: Wi-Fi 2.4GHz (IEEE 802.11b/g/n)
- Depozitare: MicroSD Card (up to 128GB, not included), Cloud Storage (subscription required)
- Audio: Audio bidirecțional (microfon și difuzor încorporate)
- Vedere de noapte: infraroșu (IR)
- Putere: DC 5V/1A
- Temperatura de functionare: 0°C până la 40°C (32°F până la 104°F)
- Dimensiuni: (Approximate) 100mm x 70mm x 70mm
Notă: Specificațiile pot fi modificate fără notificare prealabilă.
Garanție și suport
For warranty information, technical support, or further assistance, please refer to the official Cinnado website or contact their customer service directly. Details are typically found on the product packaging or the manufacturer's official website-ul.
Suport online: Vizita www.cinnado.com/support
Asistență prin e-mail: support@cinnado.com
