1. Introducere
This manual provides comprehensive instructions for the installation, operation, and maintenance of your REVODATA 5MP Mini POE IP Camera (Model I704-2-P). Please read this manual thoroughly before using the product to ensure correct usage and optimal performance. This camera is designed for both indoor and outdoor surveillance, offering high-resolution video and night vision capabilities.
Caracteristici cheie:
- UltraHD 5MP (2880 x 1620P) video resolution at 20 fps.
- IP65 Weatherproof rating for outdoor and indoor use.
- Standard 48V POE (Power Over Ethernet) 802.3af support.
- 10M IR Night Vision with 12PCS IR LEDs.
- Compact design (6 x 4.5 x 6 cm, 0.2kg).
- H.265 video encoding for efficient storage and bandwidth usage.
- Motion Detection with smartphone notifications.
- Compatible with most NVRs and accessible via "TSEYE" smartphone app and VMS software for Windows.
2. Conținutul pachetului
Verificați dacă toate articolele sunt prezente în colet:
- 1 x REVODATA 5MP Mini POE IP Camera
- 1 x Manual de utilizare
- 1 x Set de șuruburi pentru montare
- 1 x Waterproof Cap for Ethernet connection
Image: Diagram illustrating the camera's dimensions, lens, IR LEDs, auxiliary power port, RJ45 PoE port, and the included accessories: camera, waterproof cap, screws set, user manual, and product box.
3. Produs terminatview
The REVODATA I704-2-P camera features a compact metal shell with a 3.6mm lens, providing a 75-degree field of view. It is equipped with 12 IR LEDs for night vision and supports both Power Over Ethernet (PoE) and an auxiliary 12V/2A power input.
Imagine: Detaliată view of the camera highlighting its 3.6mm lens, 12 IR LEDs, auxiliary power port (12V 2A), RJ45 port (supporting PoE), and mounting brackets. Dimensions are shown as 6cm x 4.5cm x 6cm.
4. Configurare
4.1 Instalare fizică
The camera can be wall-mounted using the included screws. Choose a location that provides the desired viewing angle and is within reach of your network cable (for PoE) or power adapter. Ensure the mounting surface is stable and can support the camera's weight.
4.2 Conectarea la rețea și la alimentare
The REVODATA I704-2-P supports Power Over Ethernet (PoE), simplifying installation by delivering both power and data through a single Cat5/6 Ethernet cable. Connect the camera's RJ45 port directly to a PoE switch or a PoE injector. Alternatively, if PoE is not available, connect a 12V/2A power adapter (not included) to the auxiliary power connector and an Ethernet cable to the RJ45 port for data.
For outdoor installations, use the provided waterproof cap to protect the Ethernet connection from moisture.
4.3 Configurare software
To access and manage your camera, you can use the dedicated smartphone application or PC software.
- Aplicație pentru smartphone: Download the free "TSEYE" app from your smartphone's app store (available for Android and iOS). Follow the in-app instructions to add your camera.
- Software pentru PC: For Windows users, VMS software is available. This software allows for advanced configuration and monitoring. (Note: VMS software is not compatible with MAC OS or Linux).
Image: Screenshot of the TSEYE mobile application interface, showing login and live view options for the security camera.
Image: Screenshot of the VMS (Video Management System) software running on a desktop computer, displaying a live feed from the security camera.
5. Instrucțiuni de utilizare
5.1 În direct View
Once the camera is connected and configured through the TSEYE app or VMS software, you can access the live video feed. The camera provides a 5MP UltraHD resolution (2880 x 1620P) for clear and detailed images.
Image: A side-by-side comparison demonstrating the difference in clarity between 1080P (2MP) and 5MP (2880x1620 pixel) video resolution, showing significantly more detail in the 5MP image.
5.2 Vedere nocturnă
The camera is equipped with 12 IR LEDs, enabling night vision up to 10 meters. It automatically switches between day and night modes based on ambient light conditions, providing continuous surveillance in low-light or total darkness.
Image: A split image showing the same indoor scene during the day (color) and at night (black and white IR night vision), demonstrating the camera's ability to capture clear footage in both conditions.
5.3 Detectarea mișcării
Configure motion detection settings through the app or VMS software. When motion is detected, the camera can send alarm notifications directly to your smartphone, allowing for immediate awareness of activity in the monitored area.
Image: A smartphone displaying a notification from the TSEYE app indicating a "Device Alarm" due to motion detection, with a visual representation of a person triggering the alarm in a monitored area.
5.4 H.265 Encoding
The camera utilizes H.265 video encoding, which is more efficient than H.264. This technology reduces bandwidth consumption and saves disk space while maintaining high video quality, optimizing your storage and network resources.
Image: A visual comparison showing how H.265 encoding requires less bandwidth and storage compared to H.264 for the same video quality, represented by fewer grid squares for H.265.
6. Întreținere
Întreținerea regulată asigură longevitatea și performanța optimă a camerei dumneavoastră.
- curatenie: Ștergeți ușor obiectivul camerei și carcasa cu o lavetă moale șiamp Evitați utilizarea substanțelor chimice dure sau a materialelor abrazive care ar putea zgâria obiectivul sau deteriora finisajul.
- Actualizări firmware: Verificați periodic producătorul website or the TSEYE app for available firmware updates. Keeping your camera's firmware up-to-date can improve performance, add new features, and enhance security.
- Verificarea cablului: For outdoor installations, regularly inspect the Ethernet cable and waterproof cap for any signs of wear or damage. Ensure the waterproof cap is securely fastened to prevent moisture ingress.
7. Depanare
If you encounter issues with your REVODATA I704-2-P camera, refer to the following common troubleshooting steps:
- Camera nu pornește:
- Ensure the PoE switch or injector is active and providing power.
- If using an auxiliary power adapter, verify it is a 12V/2A adapter and properly connected to a working power outlet.
- Verificați dacă există deteriorări la cablul Ethernet.
- No Video Feed / Cannot Connect to Camera:
- Verify the camera is properly connected to your network via Ethernet.
- Ensure your network (router/switch) is functioning correctly.
- Confirm the camera's IP address is within your network's range and not conflicting with other devices. You may need to use a network scanner tool to find the camera's IP.
- Restart the camera by disconnecting and reconnecting its power source.
- If using an NVR, ensure it is compatible with ONVIF standards and that the camera is added correctly according to your NVR's instructions.
- Poor Night Vision / Condensation Inside Lens:
- Asigurați-vă că obiectivul camerei este curat și fără obstrucții.
- For outdoor cameras, condensation can occur due to extreme temperature fluctuations. While the camera is IP65 rated, severe conditions can sometimes lead to internal moisture. Ensure the waterproof cap is tightly sealed.
- If IR LEDs are too bright or not turning off, check camera settings in the app/VMS for IR control options.
- Detectarea mișcării nu funcționează:
- Review motion detection settings in the TSEYE app or VMS software. Ensure the detection area is correctly configured and sensitivity levels are appropriate.
- Check notification settings on your smartphone to ensure the TSEYE app has permission to send alerts.
8. Specificații
| Numele modelului | I704-2-P-TS |
| Rezoluție captură video | 5MP (2880 x 1620P) |
| Frame Rate | 20 de cadre pe secundă |
| Obiectiv | 3.6mm |
| Viewunghiul ing | 75 de grade |
| Distanța de vedere pe timp de noapte | 10 m (33 picioare) |
| Număr de LED-uri IR | 12 |
| Tehnologia de conectivitate | Cablat (Ethernet) |
| Sursa de alimentare | Corded Electric (PoE 48V 802.3af or 12V/2A auxiliary) |
| Utilizare în interior/exterior | În interior, în aer liber |
| Nivel de rezistență la apă | IP65 rezistent la apa |
| Material | Metal |
| Dimensiunile produsului | 1.77 x 2.36 x 2.36 inchi (4.5 x 6 x 6 cm) |
| Greutatea articolului | 9.5 uncii (0.27 kg) |
| Dispozitive compatibile | Smartphone (Android, iOS), PC (Windows) |
| Format de captură video | AVI (H.265 Encoding) |
9. Garanție și asistență
9.1 Informații despre garanție
Please refer to the product packaging or the official REVODATA website for specific warranty terms and conditions. Typically, products come with a limited manufacturer's warranty covering defects in materials and workmanship.
9.2 Asistență pentru clienți
For technical assistance, troubleshooting, or inquiries regarding your REVODATA 5MP Mini POE IP Camera, please contact REVODATA customer support. Contact information can usually be found on the product packaging, the official REVODATA website, or within the TSEYE mobile application.
Ensure you have your product model (I704-2-P) and any relevant purchase information ready when contacting support.
