Manual de utilizare pentru camera de interior BoyKeep 2K Wi-Fi

1. Introducere

This manual provides detailed instructions for setting up, operating, and maintaining your BoyKeep 2K Wi-Fi Indoor Camera. Designed for indoor surveillance, this camera offers high-resolution video, two-way audio, motion detection, and versatile storage options, making it ideal for monitoring pets, babies, or general home security.

Figure 1: BoyKeep 2K Wi-Fi Indoor Camera (White model).

2. Conținutul pachetului

• BoyKeep 2K Wi-Fi Indoor Camera (Model K30)
• Adaptor de alimentare
• Cablu de alimentare USB
• Accesorii de montaj
• Manual de utilizare (acest document)

3. Ghid de instalare

3.1 Pornirea inițială

1. Despachetați camera și toate accesoriile.
2. Connect the USB power cable to the camera's power port and the power adapter.
3. Plug the power adapter into a standard electrical outlet. The camera will power on and initiate its self-test.
4. Wait for the camera's indicator light to flash, indicating it is ready for connection.

3.2 Instalarea aplicației și crearea contului

1. Download the "BoyKeep" app from your smartphone's app store (available for Android and iOS).
2. Deschide aplicația și urmează instrucțiunile de pe ecran pentru a crea un cont nou sau pentru a te conecta dacă ai deja unul.

3.3 Conectarea la Wi-Fi

1. In the BoyKeep app, tap the "+" icon to add a new device.
2. Selectați modelul camerei din listă.
3. Follow the app's instructions to connect the camera to your Wi-Fi network. The camera supports both 2.4 GHz and 5 GHz Wi-Fi bands.
4. Ensure your smartphone is connected to the same Wi-Fi network you intend to connect the camera to.
5. Scan the QR code displayed on your phone screen with the camera lens when prompted. Hold the phone approximately 15-20 cm (6-8 inches) from the camera.
6. Once connected, the camera's indicator light will turn solid, and you will hear a confirmation sound.

Figure 2: Illustrates the camera's 355° horizontal pan and 95° vertical tilt capabilities, along with key features like motion tracking, two-way audio, 2K video, and night vision.

4. Instrucțiuni de utilizare

4.1 În direct View și control panoramic/înclinat

• Open the BoyKeep app and select your camera from the device list to access the live view.
• Use the directional controls within the app to pan the camera horizontally (355°) and tilt it vertically (95°) to adjust the viewunghiul de ing.

Figure 3: The camera offers a wide 360-degree coverage, allowing comprehensive monitoring of your space.

4.2 Sunet bidirecțional

• Din live view, atingeți pictograma microfonului pentru a vorbi prin difuzorul camerei.
• Atingeți pictograma difuzorului pentru a asculta sunetul din împrejurimile camerei.

Figure 4: The camera supports two-way audio, enabling communication with individuals near the camera.

4.3 Detectarea mișcării și alertele

• Enable motion detection in the app settings to receive real-time alerts on your smartphone when motion is detected.
• Adjust sensitivity levels and set specific monitoring zones to minimize false alarms.
• The camera can automatically track detected motion and record video clips.

Figure 5: The camera features intelligent AI detection and tracking for people and pets, capturing key moments.

4.4 Vedere nocturnă

• The camera automatically switches to night vision mode in low-light conditions using its infrared LEDs.
• Aceasta oferă imagini video alb-negru clare.tage up to 10 meters in complete darkness.

Figure 6: The camera provides clear 24-hour crystal-clear vision, including effective night vision.

4.5 Opțiuni de înregistrare și stocare

• Stocare în cloud: The camera offers free cloud storage for 12-second event clips over the last 24 hours (requires activation in the app). This provides a secure backup.
• Stocare pe card Micro SD: Insert a Micro SD card (up to 128 GB, not included) into the camera's slot for continuous recording or event-triggered recording.

Figura 7: Pesteview of versatile storage options, including free cloud storage for 12-second event clips and 24/7 recording support via Micro SD card (up to 128GB, not included).

4.6 Enabling Cloud Recording (App Instructions)

1. Open the BoyKeep app and select your camera.
2. Du-te la [eu] → [My Cloud Service] pentru a verifica starea.
3. Navigați la [Setări] → [Memorie] și activați [Record to Cloud].
4. Choose your video source from [Setări] → [Memorie], or click the SD card button on the live page.

5. Întreținere

• curatenie: Ștergeți ușor obiectivul și corpul camerei cu o cârpă moale și uscată. Nu utilizați agenți de curățare lichizi sau materiale abrazive.
• Actualizări de software: Regularly check the BoyKeep app for firmware updates to ensure optimal performance and security.
• Plasare: Ensure the camera is placed on a stable surface or securely mounted to prevent accidental falls. Avoid placing it in direct sunlight or near heat sources.

6. Depanare

7. Specificații

8. Garanție și asistență

BoyKeep provides a 24-month warranty for this product. For any issues, questions, or suggestions, please contact BoyKeep customer support. They aim to provide 100% satisfactory solutions within 3 working days.

You can typically find support contact information within the BoyKeep app or on the official BoyKeep website-ul.
