Introducere
This manual provides comprehensive instructions for the GNCC 2K Outdoor Security Camera (Model: GT1PRO Black Caméra Surveillance). It covers setup, operation, maintenance, and troubleshooting to ensure optimal performance and security for your home or business. The camera features 2K Ultra HD resolution, night vision, motion and sound detection, two-way audio, and is IP65 weatherproof for reliable outdoor use.
Image: The GNCC 2K Outdoor Security Camera, a black bullet-style camera with two antennas, shown with its packaging.
Ce este în cutie
Verificați dacă toate componentele sunt prezente în pachet:
- GNCC 2K Outdoor Security Camera
- Manual de instructiuni
- Stand
- Adaptor de alimentare
- Șuruburi de montare
Caracteristici cheie
- 2K Ultra HD & Night Vision: Captures clear video in 2K resolution. Enhanced night vision provides visibility up to 50 feet (15 meters) in total darkness.
- Detectare inteligentă AI: Provides real-time alerts for motion and sound. AI technology can identify people, pets, packages, and vehicles to reduce false alarms (subscription may be required for advanced AI features).
- Wired Power & Secure Connectivity: Operates on a reliable wired power supply and supports 2.4GHz WiFi for stable connection.
- Stocare locală și în cloud: Supports Micro SD card storage up to 128GB (not included) and offers encrypted cloud storage with a 14-day free trial.
- IP65 Weatherproof & Two-Way Audio: Designed for outdoor use with IP65 waterproof protection, withstanding temperatures from -4°F to 120°F. Features a built-in microphone and speaker for real-time two-way communication.
- Integrare Smart Home: Compatible with Amazon Alexa and Google Home for voice control and seamless integration into your smart home ecosystem.
Image: Visual representation of key features including 2K HDR, Siren, 2.4GHz WiFi, IP65, AI Detection, Night Vision, Motion Detection, Two-Way Audio, and Cloud/SD Storage.
Ghid de instalare
1. Instalarea aplicației
Download the "Osaio" app from Google Play Store (for Android) or Apple App Store (for iOS). Register an account and log in.
Image: A smartphone screen displaying Osaio app notifications for motion and sound detection.
2. Alimentarea camerei
Connect the camera to a power source using the provided USB cable and power adapter. Ensure the power outlet is within reach of the camera's cable.
The camera is USB powered, allowing flexibility for indoor use by connecting to a laptop, computer, or any USB outlet. For outdoor installation, use the provided wall adapter.
Video: A step-by-step guide demonstrating how to connect the GNCC security camera to the Osaio app using WiFi and AP modes.
3. Conectarea la WiFi
The camera supports 2.4GHz WiFi only. Ensure your router is set to this frequency for connection.
- Open the Osaio app and select "Add Camera".
- Choose your preferred connection mode: QR code (recommended) or Hotspot (AP Mode).
- Follow the on-screen instructions to connect the camera to your WiFi network. For QR code mode, present the generated QR code to the camera lens. For AP mode, connect your phone to the camera's hotspot.
- Wait for the indicator light to confirm successful connection (usually turns white or green).
Image: Diagram illustrating connection options: Hotspot, Bluetooth+WiFi, and QR Code.
4. Montarea camerei
Choose a suitable location for mounting, ensuring it is close to a power outlet and has good WiFi signal strength. The camera is IP65 weatherproof, suitable for outdoor installation.
- Marcați și găuriți găurile pentru suportul de montare.
- Use the provided mounting screws to securely attach the bracket to the desired surface.
- Screw the camera onto the mount and adjust its position for optimal viewing angle. Tighten the mount once the desired angle is achieved.
- Use the included clips to secure the power wire along the mounting surface for a neat and secure installation.
Video: A demonstration of mounting the GNCC 2K Outdoor Security Camera, including drilling holes, attaching the bracket, and securing the wire.
Image: The GNCC outdoor camera mounted near a door, illustrating its motion detection capabilities.
Operarea camerei
Trăi View & Înregistrare
Access live video feed anytime, anywhere through the Osaio app. The camera supports 24/7 continuous recording when a Micro SD card is inserted (up to 128GB). Cloud storage options are also available.
Image: A smartphone displaying a timeline of recorded events from the outdoor camera, emphasizing 24/7 recording capability.
Detectare mișcare și sunet
Receive instant real-time alerts on your phone when motion or sound is detected. The camera's AI-powered technology helps differentiate between people, pets, packages, and vehicles, reducing unnecessary notifications. You can also activate a built-in siren via the Osaio app to deter intruders.
Imagine: O imagine de sus view of a driveway showing the camera's ability to detect and categorize different objects like humans, pets, and vehicles.
Audio bidirecțional
Utilize the integrated microphone and speaker for clear two-way communication. This feature allows you to speak with visitors, delivery personnel, or deter unwanted guests directly through the app.
Image: The GNCC camera with sound waves indicating two-way audio communication between a person and children playing.
Vedere de noapte
The camera provides enhanced night vision, allowing you to see clearly up to 50 feet (15 meters) even in complete darkness, ensuring round-the-clock surveillance.
Image: A dog playing with a toy, with a "2K HDR" overlay, demonstrating the camera's high-resolution capabilities.
Întreţinere
Rezistență la intemperii
The GNCC camera is IP65 weatherproof, designed to withstand various outdoor conditions including rain, wind, and extreme temperatures ranging from -4°F to 120°F (-20°C to 49°C).
Image: The GNCC camera with water droplets, highlighting its IP65 waterproof rating.
Curatenie
Pentru a menține performanța optimă, curățați periodic obiectivul camerei și carcasa cu o lavetă moale și delicată.amp cloth. Avoid using harsh chemicals or abrasive materials that could damage the camera's surface or lens.
Depanare
- Probleme de conectare: Ensure your WiFi network is 2.4GHz. Place the camera close to your router during initial setup. If connection fails, try resetting the camera and repeating the setup process.
- Alarme false: Adjust the motion detection sensitivity settings within the Osaio app. Consider setting up specific detection zones to focus on critical areas and minimize unwanted alerts.
- Fără înregistrare: Verify that a Micro SD card is properly inserted and formatted. If using cloud storage, ensure your subscription is active.
- Vedere nocturnă slabă: Ensure the camera lens is clean and free from obstructions. Check for any strong light sources directly facing the camera at night, which could interfere with infrared illumination.
Specificații
| Caracteristică | Detaliu |
|---|---|
| Marca | GNCC |
| Numele modelului | GT1ProB |
| Rezoluție captură video | 2K |
| Tehnologia de conectivitate | Fără fir (Wi-Fi 2.4 GHz) |
| Utilizare în interior/exterior | Interior/Exterior |
| Sursa de alimentare | Electric cu fir (5 volți, 5 wați) |
| Nivel de rezistență la apă | IP65 rezistent la intemperii |
| Gama de vedere nocturnă | 50 picioare |
| Audio bidirecțional | Da |
| Detectare mișcare/sunet | Yes (Smart AI Detection) |
| Opțiuni de stocare | Micro SD (până la 128 GB), Stocare în cloud |
| Compatibilitate Smart Home | Alexa, Google Home |
| Dimensiuni (L x l x H) | 4.33 x 3.07 x 2.09 inci |
| Greutatea articolului | 7.4 uncii (210 grame) |
Garanție și asistență
For any questions or support needs, please contact GNCC customer service at support@gnchome.com.
