Introducere
Thank you for choosing the Sarmert Front Dash Cam 2K. This manual provides detailed instructions for the installation, operation, and maintenance of your dash camera. Please read this manual thoroughly before using the product to ensure proper function and safety.
Informații de siguranță
- Asigurați-vă că camera de bord este instalată într-un loc care nu obstrucționează vederea șoferului. view sau interferează cu funcționarea vehiculului.
- Do not expose the device to extreme temperatures, direct sunlight for prolonged periods, or excessive moisture. The working temperature range is -200C to 700C (-40F to 1580F).
- Folosiți doar cablul de încărcare și accesoriile furnizate.
- Nu încercați să dezasamblați sau să reparați singur dispozitivul. Contactați asistența pentru clienți pentru asistență.
- Always format the SD card before first-time use and periodically to maintain optimal performance.
Conținutul pachetului
Vă rugăm să verificați pachetul pentru următoarele articole:
- Sarmert 2K Front Dash Cam
- Type-C Cigarette Lighter Power Cable (3.5m / 11.5ft)
- Manual de utilizare
- Electrostatic Sticker (2x)
- Card SD de 64 GB
- Instrument de tăiere a firului de mașină
- Cleme pentru cablu (4x)
Image: Contents of the Sarmert Dash Cam package, including the camera, power cable, user manual, electrostatic stickers, 64GB SD card, trim tool, and cable clips.
Înființat
1. Instalarea cardului SD
Insert the provided 64GB SD card into the dash cam's SD card slot. Ensure the card is inserted correctly until it clicks into place. It is crucial to format the SD card before its first use to ensure proper functionality. The dash cam supports up to 128GB memory cards.
Image: Illustration of inserting the 64GB SD card into the dash cam's slot.
2. Montarea Dash Cam
Attach the dash cam to your windshield using the electrostatic sticker and the windshield mount. Position the camera where it has a clear view of the road but does not obstruct your driving vision. The flexible up-and-down adjustment of the 90° rotatable bracket allows you to obtain the ideal recording angle. The detachable design protects the dash camera at all times.
Image: Demonstrates the 90° rotatable angle and detachable design of the dash cam for flexible mounting.
3. Conexiune la alimentare
Connect the dash cam to your vehicle's cigarette lighter port using the provided power cable. The dash cam must always be connected to power when in use. Once connected, the dash cam will automatically begin recording when the vehicle is started.
4. App Installation & Wi-Fi Connection
The Sarmert Dash Cam supports two mobile applications: KACAM şi OMBAR. You can download these apps from your device's app store (iOS App Store or Google Play Store) or by scanning the QR code below. The Wi-Fi password can be found in the full user manual (refer to page 23 of the physical manual). The effective Wi-Fi signal range is approximately 25ft.
Image: QR code for downloading the updated app. If the Oncam APP cannot be downloaded, scan this QR code or search for "OMBAR" APP.
For more information or direct download links, visit: negruview4g.com/oncam.html
Image: Demonstrates the Wi-Fi connection between the dash cam and a smartphone for viewînregistrarea, descărcarea și partajarea videoclipurilor.
Instrucțiuni de operare
Înregistrare de bază
The dash cam automatically starts recording when powered on. It records in QHD 2560*1440P resolution with a 150° wide-angle lens, F1.8 aperture, and 6-glass lens for clear video capture.
Înregistrare în buclă
The dash cam features continuous loop recording. When the SD card is full, the oldest unlocked video files will be automatically overwritten to make space for new recordings. Videos are typically recorded in 1, 2, or 3-minute segments.
Image: Diagram illustrating endless loop recording, showing how older files are overwritten when the SD card is full.
Senzor G (Înregistrare de urgență)
The built-in G-sensor automatically detects sudden shakes or collisions. When triggered, the current video segment will be locked and saved to prevent it from being overwritten by loop recording. This ensures crucial evidence is preserved.
Image: Visual representation of G-Sensor triggering during a collision and loop recording functionality.
Blocare cu un singur clic
You can manually lock the current video recording by short pressing the Wi-Fi button once. This will protect the 1-minute video segment from being deleted by the loop recording function.
Parking Mode (24 Hours Monitoring)
For 24-hour parking monitoring, a dedicated hardwire kit is required (ASIN: B0C27S2638, not included). This function provides continuous surveillance even when your vehicle is parked. There are three modes available:
- Modul de parcare cu interval de timp: Records continuously at a low frame rate to save storage space.
- Modul de parcare de detectare a coliziunii: Activates recording only when a collision or impact is detected.
- Mod normal de parcare de înregistrare: Records continuously at normal frame rates.
Image: Illustrates the recommended hardwire kit for enabling 24-hour parking monitoring.
Night Vision & WDR Technology
The dash cam is equipped with advanced night vision capabilities and Wide Dynamic Range (WDR) technology. This multi-dynamic imaging technology effectively restores details in both bright and dimly lit areas, ensuring clear recordings even in low-light conditions.
Image: Highlights the Super Night Vision and WDR technology, showing improved clarity in various lighting conditions.
App Control & Features
The mobile app allows you to conveniently view and manage your dash cam's recordings on your iOS or Android device. You can:
- View live video feed.
- Reglați setările camerei de bord.
- Redare videoclipuri înregistrate.
- Descarcă videoclipuri pe telefon.
- Share videos directly from the app.
Note: The app does not support remote live viewing from home. The Wi-Fi connection is for direct connection between your phone and the dash camera when you need to view videos by phone.
Indemnizații vocale
The dash cam provides real-time voice prompts to inform you of its current status, such as "Recording Started," "WiFi is Connected," "Audio Off," "Parking Mode is On," and "Please Take a Rest" (Fatigue Driving Reminder). Voice prompts can be enabled or disabled via the mobile app.
Image: Illustrates various voice prompts provided by the dash cam for user convenience.
Multi-function Button & LCD Display
The dash cam features a multi-function button and a 0.96" LCD display. The button allows you to:
- Toggle Wi-Fi on/off.
- Activează/dezactivează înregistrarea audio.
- Lock the current video (short press 1 time).
- Format the SD card (long press 3s).
The 0.96" LCD screen displays the dash cam's status, including audio recording status, Wi-Fi status, memory card icon, and current time, helping to avoid setting errors.
Imagine: Detaliată view of the dash cam's multi-function button and 0.96" LCD display, showing indicators and button functions.
Întreţinere
Întreținere card SD
Regularly format your SD card (at least once a month) to prevent data corruption and ensure smooth recording. You can format the card via the dash cam's multi-function button (long press for 3 seconds) or through the mobile app.
Curățarea lentilei
To ensure clear video quality, periodically clean the dash cam's lens with a soft, lint-free cloth. Avoid using abrasive cleaners or solvents that could damage the lens.
Depanare
| Problemă | Cauză/Soluție posibilă |
|---|---|
| Camera de bord nu pornește. | Ensure the power cable is securely connected to both the dash cam and the vehicle's cigarette lighter port. Check if the vehicle's power outlet is functioning. |
| Înregistrarea se oprește sau se blochează. | Format the SD card. Ensure you are using a high-speed (Class 10 or U1/U3) SD card. The card may be full or corrupted. |
| Video quality is blurry or unclear. | Clean the dash cam lens. Ensure the protective film has been removed from the lens. Check if the windshield is clean where the camera is mounted. |
| Probleme cu conexiunea Wi-Fi. | Ensure the dash cam's Wi-Fi is enabled. Re-enter the Wi-Fi password (refer to the full manual for the password). Ensure your phone is within the effective Wi-Fi range (approx. 25ft). Disable Apple CarPlay or Android Auto temporarily if experiencing connection conflicts. |
| App is slow or unresponsive. | Ensure your phone's operating system is up to date. Close other background applications. Restart the app and the dash cam. |
| Videos are not saving or are being overwritten. | Ensure the SD card is not full (format if necessary). Check G-sensor sensitivity settings if emergency videos are not being locked. Manually lock important videos using the multi-function button. |
Specificații
| Caracteristică | Caietul de sarcini |
|---|---|
| Marca | sarmert |
| Model | LS07 8336 |
| Rezoluție captură video | 1440p (2K) |
| Viewunghiul ing | 150 de grade |
| Tip de afișare | LCD de 0.96 inchi |
| Dimensiunea cardului de memorie inclus | 64 GB (Supports up to 128GB) |
| Caracteristici speciale | Loop Recording, Built-In Speaker, G-Sensor, Night Vision, Compact Design, Wi-Fi, Voice Guidance |
| Sursa de alimentare | Cigarette Lighter Port (Super Capacitor, no internal battery) |
| Temperatura de operare | -20°C până la 70°C (-4°F până la 158°F) |
| Tip de montare | Suport parbriz |
| Dimensiunile produsului | 1 x 1 x 1 cm; 240 g |
Garanție și asistență
Your Sarmert Dash Cam comes with a full 12-month guarantee. We are committed to providing excellent customer service. If you have any questions or encounter any issues with your product, please do not hesitate to contact us via Amazon. Our after-sale service team is available 7 days a week, 24 hours a day, to assist you.
We also offer a 30-day free return policy.
