Manual de utilizare a camerei de securitate pentru interior Galayou G2

1. Informații importante privind siguranța

Please read all safety instructions carefully before using this product. Failure to follow these instructions may result in injury or damage.

• Plasare: Avoid placing the camera in unstable locations or within reach of children or pets.
• Putere: Use only the provided AC adapter and power cable. Disconnect power before moving the device.
• Mediu: Keep the camera away from high humidity, dust, and extreme temperatures. This product is not waterproof.
• Întreţinere: Do not attempt to disassemble or repair the camera yourself. Contact customer support for any issues.

Image: General safety guidelines for camera usage.

2. Conținutul pachetului

Verificați dacă toate articolele sunt incluse în pachetul dvs.:

• Galayou G2 Camera Unit
• Adaptor AC
• Cablu de alimentare
• Kit de montare (șuruburi, ancore)
• Japanese Instruction Manual

Image: The Galayou G2 camera and a smartphone displaying its live feed.

3. Ghid de instalare

3.1 Configurare inițială

1. Pornire: Connect the camera to power using the provided AC adapter and cable. The indicator light will turn red.
2. Descărcarea aplicației: Download the dedicated 'blurams' app from the App Store (iOS) or Google Play Store (Android).
3. Permisiunile aplicației: Ensure Bluetooth and Location permissions are enabled for the 'blurams' app in your smartphone settings.
4. Resetare cameră: Press and hold the reset button on the camera until you hear a beep sound. The indicator light will flash red and blue alternately, indicating it's ready for network connection.
5. Adăugați dispozitiv în aplicație: Open the 'blurams' app, tap 'Add Device' or the '+' icon. Select your camera model (G2 or similar D1 model) and choose 'Wi-Fi connection via Bluetooth'.
6. Conexiune Wi-Fi: Enter your 2.4GHz Wi-Fi network name and password. The camera only supports 2.4GHz Wi-Fi.
7. Scanare cod QR: The app will display a QR code. Hold your smartphone in front of the camera lens to scan the QR code. You will hear a beep sound from the camera upon successful scan.
8. Confirmarea conexiunii: The camera will announce 'Connection successful' and then 'Connecting to network'. Once connected, the indicator light will turn solid blue.

3.2 Video Guide: Bluetooth Wi-Fi Connection

Video: This video demonstrates the Bluetooth-assisted Wi-Fi connection method for the D1 camera, which is similar to the G2 model. It shows the steps from app permissions to successful network connection.

3.3 Video Guide: Camera Setup Method

Video: This video provides a general guide on how to set up a Skyworth pet camera, which can be used as a reference for the Galayou G2's setup process.

4. Instrucțiuni de utilizare

4.1 În direct View și control panoramic/înclinat

Once connected, you can access the live feed through the 'blurams' app. The camera offers a 355° horizontal rotation and 52° vertical rotation for comprehensive coverage.

• Pan/Tilt: Use the directional controls in the app to remotely adjust the camera's viewunghiul de ing.
• Zoom digital: The camera supports 4x digital zoom to view detalii.

Image: The camera's pan and tilt capabilities, offering a wide field of view.

4.2 Video Quality and Night Vision

The G2 camera features 2K high-resolution video (1440p) and a 3-megapixel CMOS sensor for clear images. It also provides advanced night vision capabilities.

• Rezoluție 2K: Enjoy clear and detailed video footage.
• Moduri de vedere pe timp de noapte: The camera supports three night vision modes: Smart Night Vision (auto-switches between color and black & white based on motion), Color Night Vision (always color), and Infrared Night Vision (always black & white).

Image: Comparison of day and night vision, demonstrating the camera's ability to record clearly in low light.

4.3 Sunet bidirecțional

Equipped with a microphone and speaker, the camera allows for real-time two-way communication.

• Speak and Listen: Talk to family members or pets through the app, and hear their responses.
• Reducerea zgomotului: The two-way audio features noise reduction for clearer sound.

Image: The camera's two-way audio feature, allowing interaction with pets.

4.4 Motion Detection & Automatic Tracking

The camera can detect motion and automatically track subjects within its field of view.

• Alerte de mișcare: Primește notificări instantanee pe smartphone atunci când detectează mișcare.
• Urmărire automată: The camera will follow detected movement, keeping the subject in frame.
• Detectarea omului: Advanced AI can differentiate between humans and other moving objects, reducing false alarms.
• Funcția de alarmă: Trigger an alarm sound from the camera via the app to deter intruders.

Image: Motion detection and alarm features, showing alerts on a smartphone.

4.5 Înregistrare și stocare

The camera supports both local and cloud storage options for continuous recording.

• Card MicroSD: Supports up to 128GB microSD cards (sold separately) for 24-hour continuous recording with automatic overwriting.
• Stocare în cloud: Optional paid cloud storage service is available for extended recording and backup.
• Compresie video: Utilizes H.264 and H.265 compression formats for efficient storage.

Images: MicroSD card recording and cloud storage options.

4.6 Modul de confidențialitate

Activate privacy mode to physically cover the camera lens, ensuring your privacy when needed.

• One-Tap Activation: Easily turn off the lens via the app.
• Physical Cover: The camera physically rotates its lens downwards, blocking the view.

Image: Privacy mode icon.

4.7 Integrare Alexa

The Galayou G2 is Alexa-certified, allowing for voice control and viewing the camera feed on compatible Alexa devices.

• Comenzi vocale: Utilizați comenzi vocale pentru a view the camera feed on an Echo Show or other Alexa-enabled screen.

Image: Alexa integration with the Galayou G2 camera.

4.8 Multi-Camera Support & Sharing

The app supports adding multiple cameras and sharing access with family members.

• Camere multiple: Monitor different areas of your home by adding several cameras to the app.
• Partajarea familiei: Share camera access with up to 4 family members simultaneously.

Image: Family sharing and multi-camera viewing.

4.9 Video Guide: Product Features

Video: This video showcases various features of a Skyworth pet camera, including its monitoring capabilities, which are comparable to the Galayou G2.

4.10 Video Guide: Blurams 300万画素 見守りカメラ

Video: This video highlights the features of a Blurams 3-megapixel monitoring camera, demonstrating functionalities similar to the Galayou G2.

4.11 Video Guide: JUFLSKY 300万画素 360°PTZ機 (Preview)

Video: O scurtă prezentareview prezentare videoasing a 300-megapixel 360° PTZ camera, similar in functionality to the G2.

5. Depanare

• Nu se poate conecta la Wi-Fi:
  • Asigurați-vă că rețeaua Wi-Fi este de 2.4 GHz. Camera nu acceptă rețele de 5 GHz.
  • Verificați corectitudinea parolei Wi-Fi.
  • Mută ​​camera mai aproape de routerul Wi-Fi.
  • Perform a factory reset on the camera and try the setup process again.
• No Live Feed:
  • Verificați-vă conexiunea la internet.
  • Ensure the camera is powered on and the indicator light is solid blue.
  • Reporniți aplicația și/sau smartphone-ul.
• Detectarea mișcării nu funcționează:
  • Verificați dacă detectarea mișcării este activată în setările aplicației.
  • Reglați sensibilitatea detectării mișcării.
  • Asigurați-vă că nu există obstacole care blochează camera view.
• Calitate video slabă:
  • Check your internet speed. A stable connection is required for optimal streaming.
  • Asigurați-vă că obiectivul camerei este curat.
  • Adjust the video quality settings in the app (e.g., from SD to 2K).

6. Specificații

7. Garanție și asistență

The Galayou G2 camera comes with a manufacturer's warranty and customer support.

• Garantie: Garanție de 1 ani de la producător.
• Suport tehnic: For any issues or questions, please contact GALAYOU customer support through the app or visit the official GALAYOU store on Amazon.
