DGYAO Red & Near Infrared Light Therapy Belt (Model R-BE) User Manual

1. Introducere

The DGYAO Red & Near Infrared Light Therapy Belt (Model R-BE) is designed to provide targeted light therapy for various body areas. Utilizing both red (660nm) and near-infrared (880nm) wavelengths, this device aims to support pain relief and promote cellular well-being. This manual provides essential information for safe and effective use of your therapy belt.

2. Informații de siguranță

Important: Please read all safety warnings and instructions before using this product.

• Consult with a healthcare professional before using this device, especially if you have pre-existing medical conditions, are pregnant, or are taking medications.
• Do not use on open wounds, damaged skin, or areas with active infections.
• Avoid direct eye exposure to the lights.
• Do not use if you have a pacemaker or other implanted electronic devices without consulting a doctor.
• A nu se lăsa la îndemâna copiilor.
• Do not immerse the device in water or use it in wet environments.
• Deconectați dispozitivul atunci când nu îl utilizați și înainte de curățare.
• Declarațiile referitoare la acest dispozitiv nu au fost evaluate de FDA și nu sunt destinate să diagnosticheze, să trateze, să vindece sau să prevină nicio boală sau afecțiune.

3. Caracteristicile produsului

• Terapie cu lumină duală: Features 216 red (660nm) and 108 near-infrared (880nm) lights, combined in a unique SMD lighting technology for targeted and effective therapy.
• Două moduri de operare:
  • Steady-on Mode: All red and infrared lights remain continuously illuminated.
  • Flickering Pulse Mode: Lights flicker at 600 times per minute, generating a 10Hz pulse rate energy for deeper penetration and enhanced cellular effects.
• Comfortable & Flexible Design: The soft, flat surface and adjustable buckle straps (14" to 51") allow for versatile application on the waist, back, shoulders, neck, elbows, arms, thighs, and knees.
• Temporizator de oprire automată: Equipped with a 20-minute automatic shut-off timer for convenient and safe usage.
• Cablu de alimentare extins: A 15 ft power cord provides ample range for use in various settings.

Image: Diagram illustrating the benefits of the DGYAO Light Therapy Belt, including alleviating body pain, rejuvenating skin cells, speeding up recovery, reducing inflammation, improving circulation, and promoting good mood.

Imagine: Prim-plan view of the DGYAO Light Therapy Belt's SMD LEDs, highlighting the 3-in-1 LED diode combining two 660nm red lights and one 880nm infrared light.

4. Conținutul pachetului

Vă rugăm să vă asigurați că toate articolele sunt prezente în colet:

• DGYAO Red & Near Infrared Light Therapy Belt (S22 Pad)
• Adaptor de alimentare
• Controler de timp
• Cordon DC

5. Configurare

Follow these steps to set up your DGYAO Light Therapy Belt:

1. Connect the wire from the power adapter to the time controller's input port.
2. Connect the DC cord to the output port of the time controller.
3. Connect the other end of the DC cord to the input port on the therapy belt.
4. Conectați adaptorul de alimentare la o priză electrică standard.

6. Instrucțiuni de utilizare

Once the device is connected:

1. Pornire/Oprire: Press the ON/OFF button on the time controller to turn the device on or off. The device has a 20-minute auto-off timer.
2. Selectați modul: Press the mode button (often labeled 'M' or similar) to switch between Steady-on Mode and Flickering Pulse Mode.
3. Adjust Intensity (if applicable): Some models may offer intensity adjustments. Refer to your controller for specific buttons.

Image: Illustration showing the two operating modes of the DGYAO Light Therapy Belt: Steady-on Mode (all lights on) and Flickering Pulse Mode (lights flicker at 10Hz).

7. Ghid de utilizare

Pentru rezultate optime și siguranță:

• Aplicație: Wrap the belt around the desired body area (waist, back, shoulder, neck, elbows, arms, thighs, knee cap). The flexible design allows for comfortable placement.
• Durata sesiunii: Each therapy session is typically 20 minutes, after which the device will automatically turn off.
• Frecvenţă: It is recommended to use the device for 1-2 therapy sessions per day for the first month.
• Hidratare: Drink water and rest between sessions to support your body's response to therapy.
• Confort: Ensure the belt is snug but not uncomfortably tight.

8. Întreținere

Îngrijirea adecvată asigură longevitatea dispozitivului dumneavoastră:

• curatenie: Disconnect the device from power. Wipe the surface of the therapy belt with a soft, damp pânză. Nu utilizați substanțe chimice dure sau produse de curățare abrazive.
• Depozitare: Depozitați dispozitivul într-un loc răcoros și uscat, ferit de lumina directă a soarelui și de temperaturi extreme.
• Inspecţie: Periodically inspect the power cord and connections for any signs of damage. Do not use if damaged.

9. Depanare

Dacă întâmpinați probleme, încercați aceste soluții comune:

If the problem persists, please contact DGYAO customer support.

10. Specificații

• Număr de model: R-BE
• Light Wavelengths: 660nm (Red Light), 880nm (Near-Infrared Light)
• Total LED-uri: 216 Red LEDs, 108 Near-Infrared LEDs
• Moduri de operare: Steady-on, Flickering Pulse (10Hz)
• Temporizator de oprire automată: 20 minute
• Adjustable Strap Length: 14 inci până la 51 inci
• Lungimea cablului de alimentare: 15 picioare
• Dimensiuni pachet: 8.27 x 6.97 x 3.03 inci
• Greutate: 1.59 lire sterline
• Producător: DGYAO

11. Garanție și asistență

For warranty information, product support, or any inquiries, please contact DGYAO customer service through the retailer where the product was purchased or visit the official DGYAO website. Vă rugăm să păstrați dovada achiziției pentru reclamații în garanție.
