Introducere
This manual provides essential information for the safe operation, maintenance, and troubleshooting of your eufy RoboVac X8 robot vacuum cleaner. Please read this guide thoroughly before using the product and retain it for future reference.
Conținutul pachetului
Verificați dacă toate componentele sunt prezente în pachet:
- RoboVac X8 Unit
- Baza de incarcare
- Adaptor de curent alternativ
- Perii laterale (2)
- Filtru suplimentar
- Instrument de curățare
- Legături de cablu (5)
- Owner's Manual and other documents
Image: The eufy RoboVac X8 robot vacuum with its charging base, power adapter, and other included accessories.
Caracteristicile produsului
- Twin-Turbine Technology: Equipped with two turbines, each generating 2000 Pa of suction power, for enhanced debris and pet hair pickup.
- Navigație laser iPath: Utilizes advanced LiDAR technology to scan and map your home, enabling intelligent navigation and obstacle avoidance for efficient cleaning.
- AI. Map 2.0 Technology: Supports saving maps for multiple floors, allowing the RoboVac to recognize and clean different levels of your home.
- UltraPack Dust Compression: Compresses dust within the dust box, increasing its capacity and reducing the frequency of emptying.
- Controlul aplicației: Manage cleaning schedules, select specific rooms, define no-go zones, and view real-time maps directly from your smartphone.
- Voice Activated Control: Compatible with Google Assistant and Amazon Alexa for convenient voice commands.
- Tehnologia BoostIQ: Automatically increases suction power when transitioning from hard floors to carpets for deeper cleaning.
Ghid de instalare
- Unpack the RoboVac: Carefully remove the RoboVac and all accessories from the packaging.
- Instalați periile laterale: Attach the two side brushes to the posts on the bottom of the RoboVac until they click into place.
- Position the Charging Base: Place the charging base on a hard, level surface against a wall. Ensure there is at least 3 ft (1 m) of clear space to the front and 1 ft (0.3 m) to either side of the charging base. Connect the AC power adapter to the charging base and a wall outlet.
- Taxă inițială: Place the RoboVac on the charging base. Ensure the charging pins on the RoboVac align with those on the base. The indicator lights will illuminate to show charging status. Fully charge the RoboVac before first use (approximately 5-6 hours).
- Descărcați aplicația eufyHome: Caută "eufyHome" in the App Store (iOS) or Google Play (Android) and download the app.
- Conectați-vă la Wi-Fi: Follow the in-app instructions to connect your RoboVac to your home Wi-Fi network. This enables smart features and remote control.
Image: The RoboVac X8 actively mapping its environment using iPath Laser Navigation.
Instrucțiuni de operare
Începerea unei curățări
- Pornire manuală: Press the power button on the RoboVac or the "Clean" button in the eufyHome app to start a cleaning cycle.
- Curățare programată: Use the eufyHome app to set up daily or weekly cleaning schedules.
- Curățarea punctelor: Place the RoboVac directly over a concentrated area of dirt and select the spot cleaning mode via the app or the spot clean button on the unit (if available).
Utilizarea aplicației eufyHome
The eufyHome app provides comprehensive control over your RoboVac X8:
- Cartografiere în timp real: View the RoboVac's cleaning path and current location.
- Curățenie personalizată: Selectați camere sau zone specifice pentru curățare.
- Zone interzise: Draw virtual boundaries on the map to prevent the RoboVac from entering certain areas.
- Reglarea puterii de aspirare: Choose from various suction modes (e.g., Standard, Max, BoostIQ).
- Istoricul curățeniei: Review past cleaning reports.
Image: A visual representation of the RoboVac X8's AI. Map 2.0 technology, showing its ability to map and navigate multiple floors.
Image: A smartphone displaying the eufyHome app interface, illustrating various control options like no-go zones, real-time mapping, and zone cleaning.
Întreţinere
Regular maintenance ensures optimal performance of your RoboVac X8. Always power off the RoboVac and disconnect it from the charging base before performing any maintenance.
Golirea colectorului de praf
- Press the release button on the top cover to open it.
- Pull out the dust collector.
- Open the dust collector cover and empty its contents into a trash bin.
- Close the dust collector cover and reinsert it into the RoboVac until it clicks into place.
Curățarea filtrului
- Remove the filter from the dust collector.
- Tap the filter to remove dust and debris.
- Rinse the filter under running water. Allow it to air dry completely before reinserting.
Curățarea periei rotative și a periilor laterale
- Use the cleaning tool to cut and remove any hair or debris tangled around the rolling brush.
- Gently pull the side brushes to remove them. Clean any hair or debris from the brushes and their posts. Reattach them securely.
Depanare
| Problemă | Cauza posibila | Soluţie |
|---|---|---|
| RoboVac nu pornește. | Baterie descărcată sau neîncărcată. | Așezați RoboVac pe baza de încărcare și asigurați-vă că este complet încărcat. |
| RoboVac se blochează frecvent. | Obstacles (cables, small objects) or tight spaces. | Clear the cleaning area of obstacles. Use the app to set no-go zones for problematic areas. |
| Performanță slabă de curățare. | Full dust collector, dirty filter, or tangled brushes. | Empty the dust collector. Clean or replace the filter. Clean the rolling brush and side brushes. |
| Nu se poate conecta la Wi-Fi. | Incorrect Wi-Fi password, 5GHz network, or poor signal. | Ensure correct 2.4GHz Wi-Fi network and password. Move RoboVac closer to the router. Restart RoboVac and router. |
| RoboVac cade pe scări. | Cliff sensors are dirty or malfunctioning. | Clean the cliff sensors on the bottom of the RoboVac with a dry cloth. |
Specificații
- Nume model: X8
- Număr de model articol: T2262121
- Dimensiuni produs: 13.58 x 13.58 x 3.85 inci
- Greutatea articolului: 7.72 lire sterline
- Baterie: Este necesară 1 baterie litiu-ion
- Recomandare de suprafață: Covor, Podele dure
- Caracteristica speciala: Fără sac
- Culoare: Alb
Garanție și suport
The eufy RoboVac X8 comes with a worry-free 12-month warranty. For technical support, warranty claims, or additional information, please refer to the contact details provided in the included owner's manual or visit the official eufy support website-ul.
