1. Configurare și instalare
1.1 Ce se află în cutie
Înainte de a începe instalarea, vă rugăm să verificați dacă toate componentele sunt prezente:
- 1 x 8MP PTZ Camera
- 1 x Ghid de pornire rapidă
- 1 x adaptor de alimentare DC 12V
- 1 x suport de montare
- Lifetime Technical Support Information
1.2 Instalare fizică
The VIKYLIN PTZ camera is designed for outdoor use and can be wall-mounted. Ensure the mounting location provides a clear field of view și se află în apropierea conexiunilor de alimentare și de rețea.
The camera supports Power over Ethernet (PoE), allowing both power and data transmission through a single Ethernet cable. If your router or switch does not support PoE, use the included DC 12V power adapter.
1.3 Network and Initial Web Configurarea interfeței
This video demonstrates the process of connecting the camera to your network and configuring its basic settings via a computer's web interface. It covers connecting the camera to a router or switch, finding the camera's IP address, modifying network settings, and accessing various camera functions.
Key steps covered in the video:
- Connect the camera to a router or network switch using an Ethernet cable.
- Connect the router/switch to your computer.
- Install the AjDevTools configuration software on your computer.
- Open the software to find the camera's IP address.
- Access your computer's Network and Internet settings to view its IPv4 Address and Gateway.
- Modify the camera's IP address to be on the same network segment as your computer, ensuring no IP conflicts.
- Enter the camera's web login interface using a web browser. The default username is 'admin' and the default password is '123456'.
- Download and install any required browser plugins pentru funcționalitate completă.
- Adjust camera image basic parameters, video parameters (Encode Mode, Resolution, FPS, Video Quality, Bit Rate), and audio settings.
- Configure TCP/IP settings and P2P functions for remote access.
- Enable and set up Motion Detection, including scheduling and defining detection areas.
- Manage user accounts and modify the camera's date and time settings.
- Perform firmware upgrades and configure auto-maintenance settings.
1.4 Configurarea aplicației mobile
The camera can be easily added to your mobile phone via the Videolink APP. This allows for real-time video viewing, playback, snapshots, and motion alerts. You can also share real-time video with others.
2. Instrucțiuni de utilizare
2.1 Controlul Panoramic, Tilt și Zoom (PTZ)
The camera offers extensive movement capabilities with 0° to 360° pan and 0° to 90° tilt. Its 25x optical zoom (4.4mm-110mm motorized lens) allows you to view distant objects in detail without compromising image quality.
2.2 Auto-Tracking and Human/Vehicle Detection
The camera features professional auto-tracking and human/vehicle detection. When a person or vehicle enters the monitored area, the camera automatically tracks their movement and sends real-time video or snapshots to your mobile device. Detection areas and sensitivity can be adjusted to minimize false alarms.
2.3 Sunet bidirecțional
Equipped with a built-in microphone and speakers, the camera supports two-way audio communication. This allows for real-time conversations with visitors or the ability to issue audible warnings to intruders directly through the camera.
2.4 Vedere nocturnă
The camera is equipped with 8 IR LEDs, providing up to 328ft (100 meters) of ultra-long night vision distance. This ensures clear image capture in low light or complete darkness.
2.5 Auto Cruise
Configure up to 8 groups of cruising routes, with each route supporting up to 16 preset positions. The camera will cyclically check these preset positions, providing continuous surveillance of your property.
2.6 Opțiuni de înregistrare
The camera supports multiple recording options without additional monthly fees. It can record to a Micro SD card (up to 512GB, not included), work with a PoE NVR (such as VIKYLIN NVR ASIN: B0DKXFQYQJ), or utilize FTP for storage.
3. Întreținere
3.1 Rezistența la intemperii
The camera is certified with an IP66 protection rating, indicating its resistance to dust and water immersion. It is designed to operate reliably in various outdoor weather conditions, with a wide operating temperature range.
3.2 Firmware Updates and Auto Maintenance
Regular firmware updates ensure optimal performance and access to new features. The camera's web interface allows for easy firmware upgrades and configuration of auto-maintenance schedules. Refer to Section 1.3 for detailed steps on accessing and navigating the web interface for these settings.
4. Depanare
- Probleme de conectivitate la rețea: If the camera is not connecting to the network, ensure the Ethernet cable is securely connected and that your router/switch is functioning correctly. Verify the camera's IP address is on the same network segment as your computer, as detailed in Section 1.3.
- Mobile App Connection Problems: If you are unable to connect via the Videolink APP, check your P2P settings in the web interface (Section 1.3) to ensure it is enabled and the QR code is correctly scanned. Ensure your mobile device has a stable internet connection.
- Detecția mișcării nu se declanșează: Review the motion detection settings in the web interface (Section 1.3). Confirm that motion detection is enabled, the detection area is correctly defined, and sensitivity/thresholds are appropriately set.
- Probleme de calitate a imaginii: Check the camera's image and video parameters in the web interface (Section 1.3) to ensure resolution, frame rate, and quality settings are optimized for your network and storage capacity.
- Fără sunet sau calitate audio slabă: Verify audio settings in the web interface (Section 1.3), ensuring audio input/output volumes are correctly adjusted and the audio encode type is suitable.
- Probleme generale de performanță: Consider performing a factory reset via the web interface (Section 1.3) if persistent issues occur. Always back up configurations before a reset. Ensure the camera's firmware is up to date.
Pentru asistență suplimentară, vă rugăm să vizitați VIKYLIN Official Store sau contactați asistența pentru clienți.
5. Specificații
| Caracteristică | Detaliu |
|---|---|
| Numărul de model | VK-GK4825 PTZ (PTZ-4825-IS2) |
| Rezoluţie | 8MP (4K) @ 20fps, 4MP @ 30fps |
| Senzor de imagine | 1 / 2.8 "Progressive Scan CMOS |
| Zoom optic | 25x (4.4-110mm Motorized Lens) |
| Zoom digital | 30x |
| Pan Range | 0° până la 360° |
| Interval de înclinare | 0° până la 90° |
| Gama de vedere nocturnă | Up to 328ft (100m) with 8 IR LEDs |
| Audio | Built-in Microphone and Speakers (Two-Way Audio) |
| Detectare | AI Human/Vehicle Detection, Auto Tracking |
| Conectivitate | PoE (802.3af), Ethernet, ONVIF, RTSP |
| Depozitare | Micro SD Card (up to 512GB), NVR, FTP |
| Rezistență la intemperii | IP66 rezistent la apa |
| Sursa de alimentare | 12V DC sau PoE |
| Material | Metal |
| Dimensiuni | 10 x 6.5 x 6.5 inci |
| Greutate | 4.3 lire sterline |
6. Garanție și asistență
VIKYLIN is committed to providing reliable security solutions. This product includes:
- Garanție limitată de 2 ani: Acoperă defectele de fabricație și defecțiunile în condiții normale de utilizare.
- Garanție de rambursare a banilor în 30 de zile: Allows for returns within 30 days of purchase for a full refund.
- Suport tehnic pe viață: Access to expert assistance for any questions or issues you may encounter.
For warranty claims, technical support, or additional product information, please visit the VIKYLIN Official Store on Amazon sau consultați informațiile de contact furnizate pe ambalajul produsului.
