Manual de utilizare pentru sistemul de microfon wireless Pyle PDWMU211 UHF dual

1. Introducere

This manual provides detailed instructions for the setup, operation, and maintenance of your Pyle PDWMU211 Dual UHF Wireless Microphone System. This system is designed for clear, distortion-free audio transmission, suitable for various applications including karaoke, conferences, and public speaking. Please read this manual thoroughly before using the product to ensure proper function and longevity.

2. Conținutul pachetului

Verificați dacă toate articolele enumerate mai jos sunt incluse în colet. Dacă lipsesc sau sunt deteriorate articole, vă rugăm să contactați serviciul de asistență pentru clienți.

Descrierea imaginii: Un pesteview of the Pyle PDWMU211 system components, including the receiver, two transmitters, two headset microphones, two lavalier microphones, a rechargeable battery, AA batteries, a 3.5mm adapter, and a USB cable.

• Receiver Base (1)
• Beltpack Transmitter (2)
• Headset Microphone (2)
• Lavalier Microphone (2)
• Rechargeable Battery (for Receiver) (1)
• AA Batteries (for Transmitters) (4)
• Adaptor de 3.5 mm (1)
• Cablu de încărcare USB (1)
• Power Cable / Power Adapter (1)

3. Instrucțiuni de configurare

3.1 Configurarea receptorului

Descrierea imaginii: A diagram illustrating the components of the receiver, including the 6.35mm audio plug, power switch, power/charging indicator, DC 5V charging port, RF signal indicator, antenna, and battery compartment with a rechargeable battery.

1. Încărcați receptorul: Insert the rechargeable battery into the receiver's battery compartment. Connect the USB charging cable to the DC 5V charging port on the receiver and plug the other end into a USB power source (e.g., computer, USB wall adapter). The power/charging indicator will illuminate during charging.
2. Conectare la sistemul audio: Insert the 6.35mm audio plug of the receiver into the microphone input jack of your amplifier, mixer, or audio system. If your system requires a 3.5mm input, use the provided 3.5mm adapter.
3. Poziționați antena: Ensure the receiver's antenna is extended and positioned for optimal signal reception.

3.2 Configurarea emițătorului

Descrierea imaginii: A diagram detailing the bodypack transmitter, showing the volume adjust/ON/OFF button, microphone connector, antenna, LED display, CH button down, CH button up, and the battery compartment requiring two AA batteries.

1. Instalați bateriile: Open the battery compartment on each beltpack transmitter and insert two AA batteries, observing correct polarity.
2. Conectați microfonul: Plug either the headset microphone or the lavalier microphone into the microphone connector on the beltpack transmitter. Secure the connection by screwing the connector into place.
3. Wear Transmitter: Attach the beltpack transmitter to your clothing using the integrated clip. Position the microphone appropriately (e.g., headset mic over your head, lavalier mic clipped to your lapel).

Descrierea imaginii: Un prim plan view of a hand connecting a microphone cable to the input jack of the Pyle PDWMU211 bodypack transmitter.

Descrierea imaginii: A hand inserting two AA batteries into the open battery compartment of the Pyle PDWMU211 bodypack transmitter.

4. Instrucțiuni de utilizare

4.1 Pornire/Oprire

1. Receptor: Slide the power switch on the receiver to the "ON" position. The power indicator will light up.
2. Transmiţător: Rotate the volume adjust/ON/OFF button on the beltpack transmitter clockwise to turn it on. The LED display will illuminate, showing the current frequency and battery level.

4.2 Selectarea frecvenței

The Pyle PDWMU211 system offers up to 8 selectable UHF channels to avoid interference.

1. With the transmitter powered on, press the "CH Up" or "CH Down" buttons located inside the battery compartment to cycle through available frequencies.
2. Ensure that the transmitter and receiver are set to the same frequency for proper communication. The receiver's RF signal indicator will confirm a successful connection.

4.3 Reglarea volumului

• Transmiţător: Adjust the output volume of the microphone using the volume adjust/ON/OFF knob on the beltpack transmitter.
• Receptor: The receiver base features independent and adjustable channel volume controls. Use these to fine-tune the overall output level to your audio system.

4.4 Operational Range

The system has an operation range of up to 160+ feet. Optimal performance is achieved in open areas with minimal obstructions.

Descrierea imaginii: A person wearing a headset microphone and a beltpack transmitter, presenting in a room, illustrating the wireless freedom and operational range of the system.

5. Întreținere

• curatenie: Use a soft, dry cloth to clean the surfaces of the receiver and transmitters. Avoid using liquid cleaners or solvents.
• Îngrijirea bateriei:
  • Remove AA batteries from transmitters if the system will not be used for an extended period to prevent leakage.
  • Ensure the receiver's rechargeable battery is fully charged before long storage periods and recharged periodically to maintain battery health.
• Depozitare: Depozitați sistemul într-un loc răcoros și uscat, ferit de lumina directă a soarelui și de temperaturi extreme.

6. Depanare

7. Specificații

Specificații transmițător:

• Ieșire RF:> 10 dBm
• Tip de modulare: FM
• Deviație maximă: ± 40 KHz
• Emisiune falsă:> 55 dBc
• Consum de curent nominal: <100mA
• Power Supply: 2x AA Batteries

Specificații receptor:

• Raport semnal/zgomot: -105dB
• Respingere frontieră la canal:> 70dB
• THD: <1%
• Nivel de ieșire audio: 0-300 mV
• Dimensiuni: 6.8 x 5.3 x 1.7 inci
• Power Supply: 110/220V (12-15V Power Adapter) / Rechargeable Battery

Specificații generale ale sistemului:

• Sistem de microfon cu bandă UHF
• Operation Range: Up to 160'+ ft.
• Interval de frecvență selectabil: până la (8) canale
• Audio Output Jack: 1/4"
• Balanced Output Jack: XLR
• Greutatea articolului: 1.21 kg
• Dimensiuni pachet: 12.36 x 7.64 x 2.6 inci

8. Garanție și asistență

Pentru informații despre garanție sau asistență tehnică, vă rugăm să consultați cardul de garanție inclus împreună cu produsul sau să vizitați site-ul oficial Pyle. webPăstrați bonul fiscal ca dovadă a achiziției.

Oficialul Pyle Website: www.pyleusa.com
