Manual de utilizare pentru sistemul de camere de securitate wireless SMONET (Model: SMJP-W823M1TM-002)

1. Introducere

This manual provides detailed instructions for the installation, configuration, and operation of your SMONET Wireless Security Camera System. This system features 5-megapixel high-resolution cameras, a 12-inch IPS monitor, two-way audio, AI human detection, IP67 weatherproofing, and a pre-installed 1TB hard disk drive for reliable surveillance.

2. Informații de siguranță

Please read and understand all safety warnings and instructions before installing and operating this product. Failure to follow these instructions may result in electric shock, fire, or serious injury.

• Ensure all power connections are secure and correctly rated for the device.
• Do not expose the monitor to extreme temperatures or direct sunlight.
• Cameras are IP67 rated for outdoor use, but ensure all cable connections are properly sealed to prevent water ingress.
• Avoid placing the camera in locations where it may be subject to strong vibrations or impact.
• Păstrați produsul departe de copii.
• Installation and home maintenance are not covered under warranty.

3. Conținutul pachetului

Verificați dacă toate articolele enumerate mai jos sunt incluse în colet. Dacă lipsesc sau sunt deteriorate articole, vă rugăm să contactați serviciul de asistență pentru clienți.

• 1 x 12-inch IPS Monitor (with 8-channel NVR and 1TB HDD integrated)
• 2 x 5MP Wireless Cameras
• 1 x Monitor Power Adapter
• 2 x Adaptoare de alimentare pentru cameră
• 1 x mouse USB
• 1 x cablu HDMI
• 1 x Cablu LAN
• 2 x Camera Antennas
• Mounting Screws and Wall Plugs for Cameras
• 1 x User Manual (Japanese)
• 2 x Autocolante de avertizare

4. Produs terminatview

4.1. 5MP Wireless Camera Features

• 5-Megapixel High Resolution: Captures clear and detailed images.
• Rezistență la intemperii IP67: Designed for outdoor use, resistant to dust and water.
• Detectarea umană AI: Reduces false alarms by distinguishing human shapes from other moving objects.
• Audio bidirecțional: Microfon și difuzor încorporate pentru comunicare.
• Viziune de noapte în infraroșu: Automatic day/night mode for clear surveillance in low light.
• 360-degree Adjustable Mount: Ball-type metal mount allows flexible positioning.
• Modul repetitor: Extends Wi-Fi signal range for stable connection over larger areas.

4.2. 12-inch IPS Monitor (NVR) Features

• Ecran IPS de 12 inchi: Oferă o gamă largă viewing angle and vibrant colors, reducing eye strain.
• Integrated 8-Channel NVR: Supports up to 8 cameras simultaneously.
• 1TB HDD Pre-installed: Ampstocare pentru înregistrare continuă.
• Compresie H.265+: Efficiently stores video, extending recording time and improving wireless stability.
• Moduri multiple de înregistrare: Schedule recording, continuous recording, and motion-activated recording.
• Telecomanda Viewing: Compatible with Android, iOS, Mac, and Windows devices for live view și redare.
• Conectivitate: Features HDMI, USB, LAN ports, and Wi-Fi.

5. Instrucțiuni de configurare

5.1. Initial Power-up and Connection

1. Install Camera Antennas: Carefully screw the antennas onto the designated ports on each camera.
2. Connect Camera Power: Plug each camera's power adapter into a power outlet and connect it to the camera. The camera's lights will illuminate upon successful power-up.
3. Connect Monitor Power: Plug the monitor's power adapter into a power outlet and connect it to the monitor. The monitor will power on automatically.
4. Conectați mouse-ul USB: Plug the USB mouse into one of the USB ports on the monitor.
5. Împerecherea automată: The cameras and monitor are pre-paired at the factory. They should automatically connect and display video feeds within a few minutes.

Ghid video: For a visual guide on unboxing and initial setup, please refer to the video below.

5.2. Configurare rețea

The system can operate wirelessly without an internet connection for local viewing. For remote monitoring via smartphone or PC, an internet connection is required.

1. Conexiune prin cablu: Connect the provided LAN cable from the monitor's LAN port to your router.
2. Conexiune wireless:
   • Right-click on the monitor screen with the mouse.
   • Navigate to "Network Settings" or a similar option.
   • Select "Wireless Network" and choose your Wi-Fi network.
   • Enter your Wi-Fi password to connect.

Ghid video: For a visual guide on connecting the monitor to your network, please refer to the video below.

5.3. Smartphone App Setup

Pentru a activa telecomanda viewing and receive alerts, download the companion app to your smartphone.

1. Descărcați aplicația: On the monitor, right-click and navigate to the "Wizard" or "App Download" section. Scan the QR code displayed on the screen with your smartphone to download the "EseeCloud" app (or similar, as indicated by the QR code).
2. Creează cont: Open the app and create a new user account if you don't have one.
3. Adăugați dispozitiv: In the app, click the "+" button to add a new device. Select "Kit" or "NVR" and scan the device ID QR code displayed on the monitor. Enter the NVR's password (default is usually blank or 'admin' if not set).
4. Trăi View: Odată adăugat, puteți view live feeds from your cameras and access other features remotely.

5.4. Instalarea camerei

The cameras can be mounted indoors or outdoors. Ensure the mounting surface is stable and provides a clear view din zona de supraveghere dorită.

1. Alegeți locația: Select a suitable location for each camera, considering power access and Wi-Fi signal strength.
2. Marcați punctele de găurire: Use the camera's base as a template to mark the drilling points on the wall or ceiling.
3. Găuri: Drill pilot holes and insert the provided wall plugs if necessary.
4. Montați camera: Fixați baza camerei pe suprafață folosind șuruburile furnizate.
5. Reglarea unghiului: Adjust the camera's angle using the 360-degree ball-type mount to cover the desired area.

Ghid video: For a visual guide on camera installation, please refer to the video below.

6. Instrucțiuni de utilizare

6.1. în direct View și afișaj multi-ecran

The 12-inch IPS monitor can display live feeds from all connected cameras simultaneously. You can switch between single-camera view, 4-split screen, or 8-split screen modes (if more cameras are added) using the NVR interface.

6.2. Sunet bidirecțional

Each camera is equipped with a microphone and speaker, allowing for two-way communication. You can speak through the camera using the smartphone app or the monitor interface.

6.3. Moduri de înregistrare

The NVR supports various recording options:

• Înregistrare continuă: Records 24/7, utilizing the 1TB HDD.
• Programați înregistrarea: Setați ore specifice pentru înregistrare.
• Înregistrare detectare mișcare: Înregistrează doar atunci când este detectată mișcare, economisind spațiu de stocare.
• AI Human Detection Recording: Advanced motion detection that only triggers recording for human shapes.

6.4. Remote Monitoring and Alerts

With the smartphone app, you can monitor your property from anywhere. The system also provides various alert notifications:

• Notificări push pentru aplicații: Receive instant alerts on your smartphone when motion or human detection is triggered.
• Alerte prin e-mail: Get email notifications with snapshots of events.
• Alarma sonor: The NVR can sound an audible alarm.
• Zone de detectare personalizabile: Define specific areas for motion detection to avoid unnecessary alerts (e.g., excluding public roads).

6.5. Redare

Poți cu ușurință review inregistrat footage on the monitor or via the smartphone app.

• Redare inteligentă: Quickly find specific events using the timeline.
• Date/Time Selection: Select specific dates and times to review înregistrări.
• Backup: Important data can be backed up via USB.

6.6. Vedere de noapte

The cameras automatically switch to night vision mode in low-light conditions, providing clear black-and-white images. The 5MP sensor and large infrared LED lights ensure detailed capture even in darkness.

7. Întreținere

• curatenie: Use a soft, dry cloth to clean the camera lens and monitor screen. Avoid abrasive cleaners.
• Actualizări firmware: Verificați periodic producătorul website or app for firmware updates to ensure optimal performance and security.
• Gestionarea hard disk-ului: The 1TB HDD will automatically overwrite the oldest footage when full. Back up important recordings regularly.
• Power Off Monitor: Use the power OFF button on the monitor to extend its lifespan when not in active use.

8. Depanare

9. Specificații

10. Garanție și asistență

SMONET provides a garanție de un an for this product. In case of any defects or issues during the warranty period, please contact our customer support for exchange or refund. We also offer suport tehnic pe viață.

A detailed Japanese instruction manual is included in the package. For further assistance, please contact our dedicated after-sales service team via phone, email, Line, or Skype.

Nota: Installation and home maintenance services are not covered under warranty.
