Introducere
The TrickleStar 7-Outlet Advanced PowerStrip is designed to provide surge protection and reduce standby power consumption for your home theater or computer setup. By intelligently managing power to connected devices, it helps save energy and protect your electronics.
Informații de siguranță
- Do not exceed the electrical ratings of the power strip.
- Use indoors only and in dry locations.
- Nu conectați la un alt robinet de alimentare relocabil.
- Ensure the power strip is plugged into a properly grounded outlet.
- A se păstra departe de copii.
Caracteristicile produsului
- 7 prize: Includes 2 'Always On' outlets and 5 'Switched' outlets.
- Priză de control: One dedicated outlet for your primary device (TV or PC) to manage the 'Switched' outlets.
- Ceramic Surge Protection: Provides robust protection against power surges (72,000 Amps / 1080 Joules).
- Indicație LED de stare: Lights for Ground, Surge Status, and Switched outlet status.
- Adjustable Threshold Switch: Allows customization for TV or PC power consumption levels.
- Filtrare zgomot: Less than 40dB noise filtering for clean power.
- Intrare RJ11: 1 volum scăzuttage optically isolated RJ11 input.
- Întrerupător de circuit: Întrerupător resetabil de 15A pentru protecție la suprasarcină.
- Dop unghiular pentru economisirea spațiului: Designed for convenient placement.
Instrucțiuni de configurare
- Connect Primary Device: Plug your main device (TV or PC) into the outlet labeled 'Control'. This device will regulate the power to the 'Switched' outlets.
- Conectați dispozitivele mereu active: Plug any electronics that require continuous power (e.g., cable box, DVR, router, modem) into the outlets labeled 'Always On'. These outlets remain powered regardless of the control device's status.
- Conectați dispozitivele comutate: Plug any peripherals that only need power when your primary device is on (e.g., DVD player, game console, printer, subwoofer) into the outlets labeled 'Switched'. These outlets will turn on or off with your control device.
- Adjust Threshold Switch (if applicable): If your power strip has an adjustable threshold switch (located on the side), set it according to your primary device's power consumption. Refer to the suggested settings below for optimal performance:
- TV Setup:
- LCD/LED 50" or Larger: High
- LCD/LED Less than 50": Med
- Tube/CRT TV: High
- Setare PC:
- Desktop: High
- Laptop: Low
- TV Setup:
- Plug in Power Strip: Plug the power strip's main cord into a grounded wall outlet. The 'Surge' and 'Ground' LED indicators should illuminate, confirming protection and proper grounding.
Ghid video de configurare
Video 1: A step-by-step guide on setting up your TrickleStar Tier 1 Advanced PowerStrip with a TV or PC, demonstrating how to connect devices to the 'Control', 'Always On', and 'Switched' outlets, and how to adjust the threshold switch.
Instrucțiuni de operare
Once properly set up, the TrickleStar Advanced PowerStrip operates automatically:
- When your primary device (TV or PC) plugged into the 'Control' outlet is turned ON, the 'Switched' outlets will receive power, allowing connected peripherals to operate. The 'Switched' LED indicator will illuminate.
- When your primary device (TV or PC) is turned OFF, the 'Switched' outlets will automatically cut power to connected peripherals, eliminating standby power draw. The 'Switched' LED indicator will turn off.
- The 'Always On' outlets provide continuous power to devices that should not be turned off.
Întreţinere
- Keep the power strip clean and free from dust. Use a dry cloth for cleaning.
- Asigurați o ventilație adecvată în jurul benzii de alimentare pentru a preveni supraîncălzirea.
- Regularly check the 'Surge' and 'Ground' LED indicators. If the 'Surge' indicator is off, the surge protection may have expired, and the unit should be replaced.
- Do not attempt to open or repair the power strip. Refer to qualified service personnel.
Depanare
| Problemă | Cauza posibila | Soluţie |
|---|---|---|
| Switched outlets do not turn on/off with control device. | Incorrect threshold setting; control device not properly connected or drawing insufficient power. | Adjust the threshold switch (High/Med/Low) to match your control device's power draw. Ensure the control device is fully plugged into the 'Control' outlet. |
| Nu există curent la nicio priză. | Power strip circuit breaker tripped; wall outlet has no power. | Check the resettable circuit breaker on the power strip and press to reset if tripped. Verify the wall outlet is functioning by plugging in another device. |
| 'Surge' LED indicator is off. | Protecția la supratensiune a fost compromisă sau a expirat. | The power strip's surge protection may no longer be active. Replace the power strip to ensure continued protection. |
| 'Ground' LED indicator is off. | Improper grounding of the wall outlet. | Ensure the power strip is plugged into a properly grounded 3-prong outlet. Consult an electrician if the outlet is not grounded. |
Specificații
- Producător: TrickleStar
- Număr de model: 188LV-US-7XX
- Dimensiuni produs: 39.37 x 6.35 x 3.81 cm
- Greutatea articolului: 748 g
- Culoare: Negru
- Material: Metal
- Voltage: 120 volți
- AmpCapacitate de utilizare: 15 Amps
- Total prize de curent: 7 (2 Always On, 5 Switched)
- Protecție la supratensiune: 1080 Jouli / 72,000 Amps
- Filtrare zgomot: <40dB
- Caracteristici speciale: On And Off Switch, Surge Protection, Optically Isolated RJ11 Input
Garanție și asistență
For warranty information, technical support, or any questions regarding your TrickleStar 7-Outlet Advanced PowerStrip, please contact TrickleStar directly:
- Website: www.tricklestar.com
- Telefon: 1-888-700-1098
- E-mail: customer.service@tricklestar.com
