SWISSINNO 1 580 001K

Manual de instrucțiuni SWISSINNO Kit de instalare pentru capcane de cârtițe și popândăi PRO SuperCat

Model: 1 580 001K

Produs terminatview

The SWISSINNO Install Kit is an essential accessory designed to simplify the setup and ensure the precise placement of SWISSINNO SuperCat Gopher and Mole Traps. This 2-piece kit includes a 25 cm tunnel probe for locating active tunnels and a serrated hole cutter for creating the perfect trap installation hole. Engineered with durable plastic and ergonomic handles, it is built for repeated use in various soil conditions, making trap installation faster, easier, and more effective.

Componente incluse

  • 25 cm Tunnel Probe: A metal rod with a spherical end used to locate underground tunnels.
  • Serrated Hole Cutter: A tool with a handle and serrated base designed to create a 6 cm diameter hole for trap insertion.
SWISSINNO SuperCat Install Kit components: tunnel probe and hole cutter

Image: The SWISSINNO SuperCat Install Kit, showing the tunnel probe and the hole cutter.

Configurare și instalare

Follow these steps for optimal trap placement using your SWISSINNO Install Kit:

  1. Locate the Tunnel:

    Insert the 25 cm tunnel probe into the soil near fresh molehills or vole mounds. Apply gentle pressure. When the probe suddenly drops with ease, you have located an active tunnel. This indicates the ideal spot for trap placement.

    Using the tunnel probe to locate a mole or gopher tunnel

    Image: A hand demonstrating the use of the tunnel probe to find an underground tunnel, indicated by the probe sinking easily into the soil.

  2. Prepare the Hole:

    Using the serrated hole cutter, create a clean, vertical hole with a diameter of 6 cm (approximately 2.5 inches). The hole should be 1-2 cm (approximately 0.5-0.8 inches) deeper than the floor of the tunnel. Carefully remove any loose soil that falls into the passage or press it down into the hole to ensure a clear path for the trap.

    Using the hole cutter to prepare the trap installation site

    Image: The hole cutter being used to create a precise hole in the ground for trap installation, next to the tunnel probe.

  3. Set the Trap (SuperCat Trap, not included):

    Note: This kit is for use with SWISSINNO SuperCat traps (sold separately).

    Pull the top handle of your SuperCat trap upwards to set the trap mechanism. The red prongs will retract, indicating it is armed.

    Close-up of the SuperCat trap mechanism being set

    Imagine: Un prim-plan view of the SWISSINNO SuperCat trap, showing the red prongs retracted, indicating the trap is set.

  4. Insert the Trap:

    Push the set SuperCat trap into the prepared hole. Ensure the trap openings align with the direction and height of the underground tunnel. The trap should sit firmly in the hole.

  5. Secure the Trap Area:

    At the ground surface, tightly enclose the trap with grass, leaves, or loose soil. This prevents light and air from entering the hole, which can deter moles and gophers. The trap is now ready for use.

    Diagram showing proper trap installation in a tunnel

    Image: A diagram illustrating the correct placement of the SuperCat trap within a mole or gopher tunnel, showing the probe and cutter in use.

Instrucțiuni de operare

Once the trap is installed, check it regularly, ideally within 24 hours. Often, the trap will be successful within a few hours. A triggered trap indicates a successful catch. If the trap has not been triggered after a day, it may indicate no active pest in that specific tunnel section, and the trap should be moved to a new location.

Întreţinere

Proper maintenance ensures the longevity and effectiveness of your Install Kit and traps:

  • curatenie: Clean the tunnel probe and hole cutter with hot water only after each use. Do not use soap, detergents, or chemicals, as these can leave unfamiliar scents that deter pests.
  • Handling Traps: When handling the SuperCat traps, it is recommended to wear gloves to avoid transferring human scent, which can make pests wary.
  • Depozitare: Store the kit in a dry place away from direct sunlight when not in use.

Depanare

Problemă Cauză/Soluție posibilă
Trap not triggering after 24 hours. The tunnel may not be active. Relocate the trap to a new area with fresh signs of activity (e.g., new molehills).
Trap is triggered but no pest is caught. The trap might not be perfectly aligned with the tunnel, or the hole might be too wide. Ensure precise alignment and a snug fit.
Trap access portals are clogged with soil. Moles and voles sometimes push soil into the trap. Relocate the trap and rinse it with water. Consider cutting additional openings or damaging other tunnel sections to encourage use of the trapped tunnel. If the problem persists, a different type of trap may be needed.
Pests are avoiding the trap. Pests can detect human scent. Always wear gloves when handling the trap and the install kit. Clean tools with hot water only, avoiding chemicals.

Specificații

  • Marca: SWISSINNO
  • Număr de model: 1 580 001K
  • Material: Durable Plastic (Hole Cutter), Steel (Tunnel Probe)
  • Dimensiuni produs: 4.53 cm L x 2.17 cm l x 9.65 cm Î
  • Greutatea articolului: 0.47 livre (aproximativ 7.5 uncii)
  • Numar de piese: 2 (Tunnel Probe, Hole Cutter)
  • Lungimea sondei: 25 cm
  • Hole Diameter (Cutter): 6 cm
  • Specii țintă: Gopher, Mole (for use with compatible traps)

Garanție și suport

SWISSINNO products are designed for durability and effectiveness. For specific warranty information, please refer to the packaging or contact SWISSINNO customer support directly. For assistance with your Install Kit or SuperCat traps, please visit the official SWISSINNO website-ul lor web sau contactați departamentul de asistență pentru clienți. Păstrați bonul fiscal pentru reclamații în garanție.
