Faber Coral 90cm BLDC Autoclean T-Shape Chimney

1. Introducere

Thank you for choosing the Faber Coral 90cm BLDC Autoclean T-Shape Chimney. This manual provides essential information for the safe and efficient installation, operation, and maintenance of your new kitchen appliance. Please read these instructions carefully before use and retain them for future reference.

This chimney is designed for effective smoke and odor extraction, featuring a powerful 1500 m³/hr suction capacity, a durable BLDC motor, and convenient touch and gesture controls. It includes an Autoclean function and a built-in oil collector for easy maintenance.

2. Ce se află în cutie

La despachetare, vă rugăm să vă asigurați că toate articolele sunt prezente și nedeteriorate:

• 1 x Faber Coral 90cm BLDC Autoclean T-Shape Chimney
• 1 x Manual de utilizare
• 1 x card de garanție

3. Produs terminatview

The Faber Coral Chimney is a T-shape, wall-mounted unit designed for modern kitchens. Key features include:

• Tip: T-Shape, Wall Mounted
• Dimensiune: 90 cm, suitable for 4-6 burner stoves.
• Tip filtru: Filterless design for enhanced suction and reduced maintenance.
• Putere de aspirare: 1500 m³/hr, powered by a 130 Watt BLDC Motor.
• Controla: Intuitive Touch Control, Gesture Control, and Motion Sensor for easy operation and speed adjustment (9 speeds).
• Nivel de zgomot: Operates at a quiet 58dB.
• Opțiuni de instalare: Suitable for ducted installation or ductless use with an optional charcoal filter (purchased separately).
• Caracteristici speciale: BLDC Motor for efficiency and reliability, Autoclean function, Built-In Oil Collector, and 1 LED Lamp for improved visibility.

Figure 1: Ducted vs. Ductless Installation Options

Figure 2: BLDC Motor for efficiency, reliability, and low maintenance.

Figure 3: Gesture and Touch Controls for simplified cooking.

4. Instalare

Proper installation is crucial for the performance and safety of your chimney. It is recommended to have the chimney installed by a qualified technician. Before installation, ensure you have checked the cabinet size and available space.

4.1 Verificări înainte de instalare

• Măsurați lățimea: Measure the clear width between your kitchen cabinets. Common chimney widths are 60 cm, 75 cm, and 90 cm.
• Măsurați înălțimea: Measure the height from your gas stove to the desired chimney base position. For T-shape/Curved models, the recommended clearance is 28-30 inches (71-76 cm).
• Ensure adequate electrical supply is available at the installation point.

Figure 4: Chimney Dimensions (90 cm width, 40 cm depth, 51 cm height)

4.2 Ghid video de instalare

For a visual guide on installation, please refer to the official Faber Chimney Installation Guide video below. This video demonstrates key steps and considerations for a successful setup.

4.3 Ducted vs. Ductless Installation

Your Faber Coral chimney supports both ducted and ductless configurations:

• Instalare conductă: Smoke and odors are expelled outside through a duct pipe. This requires an external vent.
• Instalare fără conducte: The chimney recirculates filtered air back into the kitchen. This requires a charcoal filter (not included, contact customer support for purchase).

5. Funcționare

The Faber Coral Chimney offers multiple convenient ways to control its functions.

5.1 Atingeți Panou de control

The chimney features a sleek touch control panel. Gently tap the icons to:

• Pornire/Oprire
• Adjust suction speed (9 levels available)
• Activate the Autoclean function
• Rotiți LED-ul lamp Pornit/Oprit

Figure 5: 9-Speed Touch Switch with Motion Sensor

5.2 Gesture Control and Motion Sensor

For hands-free operation, utilize the gesture control and motion sensor:

• Pornire/Oprire: Wave your hand in front of the sensor to turn the chimney on or off.
• Reglarea vitezei: Specific hand gestures can be used to increase or decrease the suction speed. Refer to the detailed instructions in the included User Manual for precise gesture commands.

Figure 6: Gesture Controlled Operation

6. Întreținere

Regular maintenance ensures optimal performance and longevity of your Faber chimney.

6.1 Autoclean Feature

The Autoclean feature simplifies internal cleaning. Activate this function via the touch control panel. The chimney will heat and melt accumulated oil, directing it into the oil collector.

6.2 Built-In Oil Collector

The built-in oil collector gathers oil and grease during operation and the Autoclean cycle. Regularly check and empty the oil collector to prevent overflow and maintain hygiene. To clean, simply remove the collector, wash it with mild detergent, rinse, and dry thoroughly before reinserting.

Figure 7: Stainless Steel Oil Collector

6.3 Curățarea exterioară

Wipe the exterior surfaces of the chimney with a soft, damp o cârpă și un detergent blând. Evitați produsele de curățare abrazive sau substanțele chimice dure care ar putea deteriora finisajul.

7. Depanare

If you encounter any issues with your Faber Coral Chimney, please refer to the detailed troubleshooting section in the comprehensive User Manual provided in the box. For persistent problems or technical assistance, contact Faber customer support.

8. Specificații

9. Garanție și asistență

Your Faber Coral Chimney comes with a comprehensive warranty:

• Garanția motorului: 12 ani
• Garanție completă a produsului: 2 ani

For installation services, warranty claims, or any product-related inquiries, please contact Faber customer support:

Număr serviciu clienți: 1800-209-3484

Manufacturer/Importer: Franke Faber India Pvt Ltd, 1086/1/2, SANASWADI, TAL - SHIRUR, PUNE - 412208, MAHARASHTRA, INDIA.
